| Product SKU | 9656 |
|---|---|
| Series | EPYC 9006 Series |
| # of CPU Cores | 96 |
| # of Threads | 192 |
| Max. Boost Clock | 3.7 GHz |
| Base Clock | 3.05 GHz |
| L3 Cache | 512 MB |
| Default CPU Power | 400W (CPU Power Range: 220W-400W) |
| Platform | SP7 |
| Socket Count | 1P / 2P |
| PCI Express Version | PCIe 6.0 x96 |
| System Memory Type | DDR5 RDIMM, MRDIMM |
| Memory Channels | 16 |
| System Memory Specification | 8000 MT/s / 12800 MT/s |
| Per Socket Memory Bandwidth | 1024 GB/s / 1638 GB/s |
| Product ID Tray | 100-000001048 |
| AMD Infinity Guard | yes |
| Supported Technologies | AMD Infinity Guard, AMD Infinity Architecture |
AMD EPYC, Server CPUs
AMD EPYC 9656 Processor
The AMD EPYC 9656 is a 96-core, 192-thread server processor from the AMD EPYC 9006 Series, with 512 MB L3 cache, 16 memory channels, PCIe 6.0 x96 and a 400W (CPU Power Range: 220W-400W) TDP.
Overview
The AMD EPYC 9656 is a 96-core, 192-thread server processor from the AMD EPYC 9006 Series, built for the SP7 platform, with 512 MB L3 cache and a 400W (CPU Power Range: 220W-400W) TDP. It supports 16 memory channels, DDR5 RDIMM | MRDIMM, 8000 MT/s / 12800 MT/s memory speeds, 1024 GB/s / 1638 GB/s per-socket bandwidth, and provides PCIe 6.0 x96 across 1P / 2P socket configurations.
Key Features
- Performance: 96 cores and 192 threads, 3.05 GHz base clock, 3.7 GHz max boost clock
- 512 MB L3 cache, 400W (CPU Power Range: 220W-400W) TDP, SP7 platform, 1P / 2P socket configurations
- Memory: DDR5 RDIMM | MRDIMM, 16 memory channels, memory speeds of 8000 MT/s / 12800 MT/s, 1024 GB/s / 1638 GB/s per-socket bandwidth
- I/O: PCIe 6.0 x96
- Technologies: AMD Infinity Guard, AMD Infinity Architecture
Applications
- Virtualization and private cloud infrastructure
- In-memory databases and real-time analytics
- AI inference and machine learning serving
- HPC and data-intensive workloads
Configuration, availability and lead time depend on the required quantity, platform pairing and delivery destination. Send your requirement to receive a quotation.
