| Product SKU | 6337P |
|---|---|
| Product Collection | Intel® Xeon® 6 processors |
| Code Name | Products formerly Raptor Lake |
| Vertical Segment | Server |
| Lithography | Intel 7 |
| Total Cores | 6 |
| # of Performance-cores | 6 |
| Total Threads | 12 |
| Max Turbo Frequency | 5.3 GHz |
| Processor Base Frequency | 3.5 GHz |
| Cache | 18 MB |
| Bus Speed | 16 GT/s |
| TDP | 80 W |
| Marketing Status | Launched |
| Launch Date | Q1'25 |
| Servicing Status Intel Platform Update (IPU) . See "Changes in Customer Support and Servicing Updates for Select Intel Processors" for more information on servicing." data-search-title="Servicing Status" data-search-icon="true" aria-label="Servicing Status"> | Baseline Servicing |
| Embedded Options Available or contact your Intel representative. For details on how a specific Intel product is used in an edge or embedded device, please contact the device manufacturer." data-search-title="Embedded Options Available" data-search-href="/content/www/us/en/ark/featurefilter.html?productType=873&0_Embedded=True" data-search-icon="true" aria-label="Embedded Options Available"> | No |
| Use Conditions For SKU specific use condition information, see PRQ report . For current use condition information, see Intel UC (CNDA site)*." data-search-title="Use Conditions" data-search-icon="true" aria-label="Use Conditions"> | Server/Enterprise |
| Max Memory Size (dependent on memory type) | 128 GB |
| Memory Types | DDR5-4800 |
| Maximum Memory Speed | 4800 MT/s |
| Max # of Memory Channels | 2 |
| Intel Optane Persistent Memory Supported | No |
| ECC Memory Supported ‡ ‡ " data-info-description="ECC Memory Supported indicates processor support for Error-Correcting Code memory. ECC memory is a type of system memory that can detect and correct common kinds of internal data corruption. Note that ECC memory support requires both processor and chipset support." data-search-title="ECC Memory Supported ‡ " data-search-href="/content/www/us/en/ark/featurefilter.html?productType=873&0_ECCMemory=True" data-search-icon="true" aria-label="ECC Memory Supported ‡ "> | Yes |
| Max # of DMI Lanes | 8 |
| Scalability | 1S Only |
| PCI Express Revision | 5.0 |
| Microprocessor PCIe Revision | Gen 5 |
| PCI Express Configurations ‡ ‡ " data-info-description="PCI Express (PCIe) Configurations describe the available PCIe lane configurations that can be used to link to PCIe devices." data-search-title="PCI Express Configurations ‡ " data-search-icon="true" aria-label="PCI Express Configurations ‡ "> | Up to 1×16+1×4, 2×8+1×4 |
| Max # of PCI Express Lanes | 20 |
| Sockets Supported | FCLGA1700 |
| Max CPU Configuration | 1 |
| T JUNCTION JUNCTION " data-info-description="Junction Temperature is the maximum temperature allowed at the processor die." data-search-title="T JUNCTION " data-search-icon="true" aria-label="T JUNCTION "> | 100°C JUNCTION "> |
| Intel Turbo Boost Max Technology 3.0 ‡ ‡ " data-info-description="Intel Turbo Boost Max Technology 3.0 identifies the best performing core(s) on a processor and provides increased performance on those cores through increasing frequency as needed by taking advantage of power and thermal headroom." data-search-title="Intel Turbo Boost Max Technology 3.0 ‡ " data-search-icon="true" aria-label="Intel Turbo Boost Max Technology 3.0 ‡ "> | No |
| Intel Turbo Boost Technology ‡ ‡ " data-info-description="Intel Turbo Boost Technology dynamically increases the processor's frequency as needed by taking advantage of thermal and power headroom to give you a burst of speed when you need it, and increased energy efficiency when you don’t." data-search-title="Intel Turbo Boost Technology ‡ " data-search-icon="true" aria-label="Intel Turbo Boost Technology ‡ "> | 2.0 |
| Intel Hyper-Threading Technology ‡ ‡ " data-info-description="Intel Hyper-Threading Technology (Intel HT Technology) delivers two processing threads per physical core. Highly threaded applications can get more work done in parallel, completing tasks sooner." data-search-title="Intel Hyper-Threading Technology ‡ " data-search-icon="true" aria-label="Intel Hyper-Threading Technology ‡ "> | Yes |
| Intel Transactional Synchronization Extensions | No |
| Intel 64 ‡ ‡ " data-info-description="Intel 64 architecture delivers 64-bit computing on server, workstation, desktop and mobile platforms when combined with supporting software.¹ Intel 64 architecture improves performance by allowing systems to address more than 4 GB of both virtual and physical memory." data-search-title="Intel 64 ‡ " data-search-icon="true" aria-label="Intel 64 ‡ "> | Yes |
| Instruction Set | 64-bit |
| Instruction Set Extensions | Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2 |
| Idle States | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| Thermal Monitoring Technologies | Yes |
| Intel Secure Key | Yes |
| Intel Total Memory Encryption - Multi Key | Yes |
| Intel Total Memory Encryption | Yes |
| Intel AES New Instructions | Yes |
| Intel OS Guard | Yes |
| Intel Trusted Execution Technology ‡ ‡ " data-info-description="Intel Trusted Execution Technology for safer computing is a versatile set of hardware extensions to Intel processors and chipsets that enhance the digital office platform with security capabilities such as measured launch and protected execution. It enables an environment where applications can run within their own space, protected from all other software on the system." data-search-title="Intel Trusted Execution Technology ‡ " data-search-icon="true" aria-label="Intel Trusted Execution Technology ‡ "> | Yes |
| Execute Disable Bit ‡ ‡ " data-info-description="Execute Disable Bit is a hardware-based security feature that can reduce exposure to viruses and malicious-code attacks and prevent harmful software from executing and propagating on the server or network." data-search-title="Execute Disable Bit ‡ " data-search-icon="true" aria-label="Execute Disable Bit ‡ "> | Yes |
| Intel Boot Guard | Yes |
| Mode-based Execute Control (MBEC) | Yes |
| Intel Virtualization Technology with Redirect Protection (VT-rp) ‡ | Yes |
| Intel Virtualization Technology (VT-x) ‡ ‡ " data-info-description="Intel Virtualization Technology (VT-x) allows one hardware platform to function as multiple “virtual” platforms. It offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions." data-search-title="Intel Virtualization Technology (VT-x) ‡ " data-search-href="/content/www/us/en/ark/featurefilter.html?productType=873&2_VTX=True" data-search-icon="true" aria-label="Intel Virtualization Technology (VT-x) ‡ "> | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) ‡ ‡ " data-info-description="Intel Virtualization Technology for Directed I/O (VT-d) continues from the existing support for IA-32 (VT-x) and Itanium processor (VT-i) virtualization adding new support for I/O-device virtualization. Intel VT-d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments." data-search-title="Intel Virtualization Technology for Directed I/O (VT-d) ‡ " data-search-href="/content/www/us/en/ark/featurefilter.html?productType=873&0_VTD=True" data-search-icon="true" aria-label="Intel Virtualization Technology for Directed I/O (VT-d) ‡ "> | Yes |
| Intel VT-x with Extended Page Tables (EPT) ‡ ‡ " data-info-description="Intel VT-x with Extended Page Tables (EPT), also known as Second Level Address Translation (SLAT), provides acceleration for memory intensive virtualized applications. Extended Page Tables in Intel Virtualization Technology platforms reduces the memory and power overhead costs and increases battery life through hardware optimization of page table management." data-search-title="Intel VT-x with Extended Page Tables (EPT) ‡ " data-search-icon="true" aria-label="Intel VT-x with Extended Page Tables (EPT) ‡ "> | Yes |
Intel Xeon, Server CPUs
Intel Xeon 6337P Processor
The Intel Xeon 6337P Processor is a 6-core, 12-thread server CPU from the Intel Xeon 6 processor family (Raptor Lake), with 18 MB cache, 2-channel memory, PCIe 5.0 and a 80 W TDP.
Overview
The Intel Xeon 6337P Processor is a 6-core, 12-thread server CPU from the Intel Xeon 6 processor family (Raptor Lake), built on the Intel 7 process, with 18 MB cache and a 80 W TDP. It supports 2 memory channels, DDR5-4800 memory and up to 128 GB per processor, and provides PCIe 5.0 with up to 20 lanes.
Key Features
- Performance: 6 cores and 12 threads, 3.5 GHz base frequency, 5.3 GHz max turbo frequency
- 18 MB cache, 80 W TDP, 1S (single socket) scalable
- Memory: memory speeds up to 4800 MT/s, 2 memory channels, up to 128 GB per processor, DDR5-4800
- I/O: PCIe 5.0, up to 20 lanes
- Security and virtualization: Total Memory Encryption (multi-key), Intel AES-NI, Intel Boot Guard
- FCLGA1700 socket
- Launched Q1’25
Applications
- Virtualization, private cloud and container infrastructure
- In-memory databases and real-time analytics
- General-purpose server compute
- HPC and data-intensive workloads
Configuration, availability and lead time depend on the required quantity, platform pairing and delivery destination. Send your requirement to receive a quotation.
