FusionServer 5288 V6

FusionServer 5288 V6

FusionServer 5288 V6 is a 4U 2-socket rack server that meets service requirements such as hot, warm, and cold data tiered deployment and historical data archiving. With its efficient design, FusionServer 5288 V6 ensures excellent computing performance and provides flexible and ultra-large local storage expansion capabilities, reducing data storage costs. The 5288 V6 can be configured with two Intel Xeon scalable processor, 32 DDR4 DIMMs, and 44 3.5-inch + 4 NVMe SSDs in a 4 U space. Integrates patented technologies such as DEMT intelligent power management and FDM intelligent fault management, and can be configured with FusionDirector full-lifecycle management software, effectively reducing OPEX and improving ROI.

Category: Brand:
Form Factor

4U Rack Server

Processor

1/2 x 3rd Gen Intel® Xeon® Scalable processors (Ice Lake, 8300/6300/5300/4300 series), up to 270 W TDP

Chipset

Intel® C621A

Memory

32 x DDR4 memory slots, up to 3200 MT/s; up to 16 x Intel® Optane™ Persistent Memory 200 Series, up to 3200 MT/s

Local Storage

– 36 to 44 x 3.5″ SAS/SATA HDDs and 4 x NVMe SSDs
– 24 x 3.5″ SAS/SATA front hard disks
– 4 x 3.5″ SAS/SATA internal hard disks
– 16 x 3.5″ SAS/SATA hard disks and 4 x 2.5″ SAS/SATA/NVMe rear hard disks
– 12 x 3.5″ SAS/SATA disks and 8 x 2.5″ rear hard disks (4 x 2.5″ HDDs + 4 x 2.5″ SAS/SATA/NVMe)
– Flash storage: dual M.2 SSDs

RAID

Supports RAID 0, 1, 5, 50, 6, and 60, cache supercapacitor protection, RAID level migration, disk roaming, self-diagnosis, and web-based remote configuration

Network

OCP 3.0 NIC
The two FLEX I/O card slots support two OCP 3.0 NICs, which can be configured as required
Supports multiple OCP 3.0 NICs and hot swap

PCle Expansion

A maximum of 11 PCIe 4.0 slots, including one dedicated PCIe slot for the RAID controller card, two dedicated FLEX I/O slots for OCP 3.0, and eight standard PCIe 4.0 slots

Fan

4 hot-swappable fans, supporting N+1 redundancy

PSU

– 2 redundant hot-swappable PSUs in 1+1 redundancy mode; optional specifications:
– 900 W AC Platinum/Titanium PSU (input: 100–240 V AC or 192–288 V DC)
– 1500 W AC Platinum PSU: 1000 W (input: 100 V to 127 V AC); 1500 W (input: 200–240 V AC or 192–288 V DC)
– 2000 W AC Platinum PSU: 1800 W (input: 200–220 V AC or 192–200 V DC); 2000 W (input: 220–240 V AC or 200–288 V DC)

Management

– The BMC chip integrates one dedicated management GE network port to provide comprehensive management features such as fault diagnosis, automatic O&M, and hardware security hardening.
– The BMC supports standard interfaces such as Redfish, SNMP, and IPMI 2.0; provides a remote management interface based on HTML5/VNC KVM; supports out-of-band management functions such as monitoring, diagnosis, configuration, agentless, and remote control, simplifying management.
– FusionDirector management software can be used to provide advanced management features such as five intelligent features, implementing intelligent, automatic, visualized, and refined management throughout the lifecycle.

OS

Microsoft Windows Server, SUSE Linux Enterprise Server, VMware ESXi, Red Hat Enterprise Linux, CentOS, Oracle Linux, Ubuntu, Debian, openEuler, etc.

Security

Power-on password, administrator password, TPM 2.0, security panel, secure boot, and cover opening detection

Operating Temperature

5°C to 45°C (41°F to 113°F), compliant with ASHRAE Class A1/A2/A3

Certification

CE, NRTL, CCC, FCC, VCCI, RoHS, etc.

Installation Suite

L-shaped guide rails, retractable guide rails, and holding rails

Dimensions (H x W x D)

Chassis: 175 mm x 447 mm x 790 mm

FusionServer 5288 V6 is a 4U 2-socket rack server that meets service requirements such as hot, warm, and cold data tiered deployment and historical data archiving. With its efficient design, FusionServer 5288 V6 ensures excellent computing performance and provides flexible and ultra-large local storage expansion capabilities, reducing data storage costs. The 5288 V6 can be configured with two Intel Xeon scalable processor, 32 DDR4 DIMMs, and 44 3.5-inch + 4 NVMe SSDs in a 4 U space. Integrates patented technologies such as DEMT intelligent power management and FDM intelligent fault management, and can be configured with FusionDirector full-lifecycle management software, effectively reducing OPEX and improving ROI.
