FusionServer G5500 V7

FusionServer G5500 V7

FusionServer G5500 V7 (G5500 V7) is a new-generation 4U 2-socket AI server. It supports a maximum of 10 x double-width GPU cards, 4 x standard PCIe cards, and 3 x OCP NICs, and provides ultra-large capacity or ultra-fast storage through 24 x 3.5″ drives or 12 x NVMe SSDs.

G5500 V7 features high performance, flexible architecture, high reliability, easy deployment, and simplified management.

G5500 V7 accelerates applications such as AI training, AI inference, high-performance computing (HPC), image and video analysis, and database, and supports enterprise and public cloud deployment.

Category: Brand:
Form Factor

4U AI server

Processor

2 x 4th/5th Gen Intel® Xeon® Scalable processors, with up to 385 W TDP per processor

Chipset

Emmitsburg PCH

Memory

32 x DIMMs at up to 5600 MT/s, up to 256 GB per DIMM

Local Storage

Hot-swappable and flexible drive configurations:
• Up to 24 x 2.5″/3.5″ SAS/SATA drives
• Up to 12 x NVMe SSDs and 8 x SATA/SAS drives
Flash storage: dual M.2 SSDs

RAID

RAID 0, 1, 10, 5, 50, 6, and 60; supercapacitors for cache data protection against power failures;

RAID level migration, drive roaming, self-diagnosis, and remote web-based configuration

GPU Card

10 x dual-width GPU cards

Network

Multiple network expansion capabilities, 3 x OCP 3.0 NICs

PCIe Expansion

Up to 14 x standard PCIe 5.0 slots, including 10 x dedicated slots for GPU cards

Fan Module

6 or 8 x hot-swappable counter-rotating fan modules in N+1 redundancy

PSU

4 x 2000 W Platinum/Titanium, 2600 W Platinum, or 3000 W Titanium hot-swappable PSUs in N+N/N+M redundancy

Management

The iBMC chip integrates one dedicated management GE network port, providing comprehensive management features such as fault diagnosis, automatic O&M, and hardware security hardening.
• The iBMC supports standard interfaces such as Redfish, SNMP, and IPMI 2.0, provides a remote management user interface based on HTML5/VNC KVM; supports out-of-band management functions such as monitoring, diagnosis, configuration, Agentless, and remote control for simplified management.
• It is optional to configure the FusionDirector management software that provides advanced management features such as five intelligent technologies, enabling intelligent, automatic, visualized, and refined management throughout the lifecycle.

OS

Microsoft Windows Server, SUSE Linux Enterprise Server, Red Hat Enterprise Linux, and Ubuntu .

Security

Power-on password, administrator password, Trusted Platform Module (TPM) 2.0, security bezel, secure boot, and chassis intrusion detection

Operating Temperature

5℃～35℃（41℉～95℉）, compliant with ASHRAE Classes A1/A2

Certification

CCC, CQC, VCCI, and CE

Installation Suite

L-shaped guide rails, adjustable guide rails, and holding rails

Dimensions (H x W x D)

175mm x 447 mm x 898mm (6.89 in. x 17.60 in. x 35.35 in.)

FusionServer G5500 V7 (G5500 V7) is a new-generation 4U 2-socket AI server. It supports a maximum of 10 x double-width GPU cards, 4 x standard PCIe cards, and 3 x OCP NICs, and provides ultra-large capacity or ultra-fast storage through 24 x 3.5″ drives or 12 x NVMe SSDs.

G5500 V7 features high performance, flexible architecture, high reliability, easy deployment, and simplified management.

G5500 V7 accelerates applications such as AI training, AI inference, high-performance computing (HPC), image and video analysis, and database, and supports enterprise and public cloud deployment.
