| Product SKU | NF5688-A7-A0-R0-00 |
|---|---|
| Form Factor | 6U |
| Processor | 2*4th or 5th Gen Intel Xeon Scalable Processors, TDP 350W |
| Memory | 32 * DDR5 DIMMs, up to 5600MT/s |
| Storage | 24 * 2.5’ SSD, up to 16 * NVMe U.2 |
| Storage Controller | Optional support RAID 0/1/10/5/50/6/60, etc., support Cache super capacitor protection |
| Network | Optional support 1*OCP 3.0, support NCSI |
| GPU | NVIDIA HGX Hopper 8-GPU, TDP up to 700W per GPU |
| I/O Expansion | – Support 10 * PCIe Gen5 x16 slots. One PCIe Gen5 x16 slot can be replaced with two x16 slots (PCIe Gen5 x8 rate). |
| Power Supply | 2* 12V 3200W and 6* 54V 2700W, Platinum/Titanium PSU with N+N redundancy |
| Cooling | 6 hot-swap fans with N+1 redundancy |
| System Management | DC-SCM BMC management module with Aspeed 2600 |
| Security | TPM 2.0 |
| Dimensions | 447mm*263mm*860mm |
| Weight | Net weight 92kg（Gross weight 107kg） |
| Environment | Working temperature：10℃~35℃; Storage temperature：-40℃~70℃ |
Inspur NF5688G7 NF5688-A7-A0-R0-00 GPU Server
NF5688G7, the 6U hyperscale training platform equipped with dual 4th or 5th Gen Intel Xeon Scalable Processors or AMD EPYCTM 9004 Series Processors and 8x NVIDIA latest GPUs, features industry-leading performance, ultimate I/O expansion, and ultrahigh energy efficiency.
Overview
NF5688G7, the 6U hyperscale training platform equipped with dual 4th or 5th Gen Intel Xeon Scalable Processors or AMD EPYCTM 9004 Series Processors and 8x NVIDIA latest GPUs, features industry-leading performance, ultimate I/O expansion, and ultrahigh energy efficiency. The precisely optimized system architecture with 4x CPU to GPU bandwidth, up to 4.0Tbps networking bandwidth, 8TB system memory, and 300TB massive local storage can fully satisfy the communication and capacity demands of multi-dimensional parallelism training for giant-scale models. 12 PCIe expansions can be flexibly configured with CX7, OCP3.0, and multiple SmartNICs, making it an ideal solution for both on-premises and cloud deployment. It is built to handle the most demanding AI computing tasks like trillion-parameter Transformer model training, massive recommender systems, AIGC, and Metaverse workloads.
Key Features
- Unprecedented performance: Powered by 8* NVIDIA latest GPUs in a 6U chassis, TDP up to 700W Support 2x 4th or 5th Gen Intel Xeon Scalable Processors or AMD EPYCTM 9004 Series Processors Industry-leading performance by 3 times enhancement. The Transformer Engine significantly accelerates the training speed of GPT large mode
- Optimized energy efficiency: Extremely low air-cooled heat dissipation overhead, less fan, higher power efficiency 54V, 12V separated power supply with N+N redundancy reducing power conversion loss Direct liquid cooling design with more than 80% cold plate coverage, PUE≤1.15
- Leading architecture design: Lightning-fast intra-node connectivity with 4x CPU to GPU bandwidth improvement Ultra-high scalable inter-node networking with up to 4.0Tbps non-blocking bandwidth Cluster-level optimized architecture, GPU:Compute Network: Storage Network = 8:8:2
- Multi-scenarios adaptation: Full modular design and extremely flexible configurations satisfying both on-premises and cloud deployment Easily harness large-scale model training, such as GPT-3, MT-NLG, stable diffusion and Alphafold. Diversified SuperPod solutions accelerating the most cutting-edge innovation including AIGC, AI4Science and Metaverse.
Configuration, availability and lead time depend on the required quantity, system pairing and delivery destination. Send your requirement to receive a quotation.
