| Interfaces | 32 x 400GE +2 x 10GE |
|---|---|
| Switching Capacity | 25.6Tbps |
| Packet Forwarding Rate | 19200Mpps |
| Power Consumption | Typical power consumption: 528W (100% load, half the ports with copper cables, room temperature, dual AC power supplies); Maximum power consumption: 943W (100% load, all ports with short-reach optical modules, room temperature, dual AC power supplies) |
| Buffer | 144MB |
| Security | Granular micro-segmentation security isolation (IPv4 and IPv6); MACsec |
| Reliability | LACP; Hardware BFD (minimum packet interval 3ms); VRRP; M-LAG; DPFR; MoFRR; DPCF |
| Intelligent O&M | Telemetry; NetStream; sFlow; Enhanced SPAN/RSPAN/ERSPAN; IFIT; Packet Event root cause analysis |
| Data Center Features | 1588v2; RoCE V1/V2; VXLAN routing and bridging; BGP-EVPN; M-LAG; PFC, AI ECN |
| Power Supply Method | 2000W AC & 240V DC power module: AC: 90V AC to 290V AC, 45Hz-65Hz; DC: 190V DC to 290V DC; 2200W DC power module: -38.4V DC to -72V DC; +38.4V DC to +57V DC; 2000W HVDC power module: 260V DC to 400V DC |
| Power Redundancy | 1+1 backup |
Overview
The CE9855-32DQ is an enterprise data-center Ethernet switch with 32 x 400GE +2 x 10GE, 25.6Tbps switching capacity and 19200Mpps of packet forwarding. It is intended for enterprise and data-center network deployments.
At a glance
- Interfaces: 32 x 400GE +2 x 10GE
- Switching Capacity: 25.6Tbps
- Packet Forwarding Rate: 19200Mpps
- Power Consumption: Typical power consumption: 528W (100% load, half the ports with copper cables, room temperature, dual AC power supplies); Maximum power consumption: 943W (100% load, all ports with short-reach optical modules, room temperature, dual AC power supplies)
- Buffer: 144MB
- Security: Granular micro-segmentation security isolation (IPv4 and IPv6); MACsec
- Reliability: LACP; Hardware BFD (minimum packet interval 3ms); VRRP; M-LAG; DPFR; MoFRR; DPCF
- Intelligent O&M: Telemetry; NetStream; sFlow; Enhanced SPAN/RSPAN/ERSPAN; IFIT; Packet Event root cause analysis
- Data Center Features: 1588v2; RoCE V1/V2; VXLAN routing and bridging; BGP-EVPN; M-LAG; PFC, AI ECN
- Power Supply Method: 2000W AC & 240V DC power module: AC: 90V AC to 290V AC, 45Hz-65Hz; DC: 190V DC to 290V DC; 2200W DC power module: -38.4V DC to -72V DC; +38.4V DC to +57V DC; 2000W HVDC power module: 260V DC to 400V DC
- Power Redundancy: 1+1 backup
When to choose this data-center Ethernet switch
Choose this data-center Ethernet switch where the deployment needs 32 x 400GE +2 x 10GE with 25.6Tbps of capacity and 2000W AC & 240V DC power module: AC: 90V AC to 290V AC, 45Hz-65Hz;… power, plus Granular micro-segmentation security isolation (IPv4 and IPv6); MACsec.
Platform & compatibility
Supports interfaces 32 x 400GE +2 x 10GE, features 1588v2; RoCE V1/V2; VXLAN routing and bridging; BGP-EVPN; M-LAG; PFC, AI ECN, power 2000W AC & 240V DC power module: AC: 90V AC to 290V AC, 45Hz-65Hz; DC: 190V DC to 290V…, buffer 144MB. Confirm the software version, optics/transceivers and power options for your network before ordering.
Deployment notes
The CE9855-32DQ is supplied as configured hardware; software version and optics are selected at order time. power: 2000W AC & 240V DC power module: AC: 90V AC to 290V AC, 45Hz-65Hz; DC: 190V DC…. consumption: Typical power consumption: 528W (100% load, half…. buffer: 144MB. Send the required port mix, software licences and optics for a firm configuration and quote.
FAQ
What interfaces does it have? 32 x 400GE +2 x 10GE.
What is its capacity? 25.6Tbps.
What is the packet forwarding rate? 19200Mpps.
What security features does it include? Granular micro-segmentation security isolation (IPv4 and IPv6); MACsec.
How do I get pricing? Send the required configuration; quotes depend on quantity, software and destination.
