Inspur NF5280R6 Rack Server

The Inspur NF5280R6 is a 2U rack server rack server.

SKU: NF5280R6 Category: Server Brand: Inspur

Technical Specifications
Overview

Product SKU	NF5280R6
Form Factor	2U rack server
Processor	– 1 or 2 Ampere ® Altra ® / Altra Max ® processors: Up to 80 cores (3.3 GHz)/128 cores (3.0 GHz) – 2 groups of x16 CCIX links, up to 25 GT/s per link TDP up to 250 W
Memory	– 1. Up to 32 DIMMs – 2. 8 memory channels per processor, and up to 2 memory slots per channel – 3. Up to 3200 MT/s – 4. RDIMMs supported – 5. ECC, memory mirroring and memory rank sparing
Storage	– Front Drive – 12 x 3.5" or 2.5" hot-SWap SATA/SAS/NVMe drives – Rear Drive – 4 x 2.5" hot-SWap SATA/SAS/NVMe SSD drives – Onboard Drive – (optional) 1 x onboard NVMe M.2 – Up to 1 BMC TF Card
Network	– 1 optional OCP NIC 3.0 module (10 Gb/s, 25 Gb/s, 40 Gb/s, and 100 Gb/s) – Standard PCIe form factor: 1/10/25/40/100G NIC
I/O Expansion	– Up to 8 PCIe slots(Altra: 4* x16 +4* x8, Altra max:6* x16+2* x8) – 1 OCP 3.0 (Altra supports x8x8 multi-host, Altra max supports x16 single-host or x8x8 multi-host)
Ports and Interfaces	– 2 rear USB 3.0 ports + 1 front USB 3.0 port + 1 front USB 2.0 port – 1 front VGA port – 1 rear VGA port
Power Supply	– 800/1300/1600/2000 W CRPS standard PSUs with 1+1 redundancy – 110 VAC ‒ 230 VAC: 90 V ‒ 264 V – 240 VDC: 180 V ‒ 320 V
Cooling	4 hot-swap 8056 fans with N+1 redundancy
System Management	Integrated with 1 independent 1000 Mbps network port, dedicated for IPMI remote management
Operating System	RHEL 8.3, Centos 8.1, Ubuntu 18.04, Oracle Linux 8.3, and so on
Dimensions	– With mounting ears: 478. – 8 × 87 × 811.7 mm (18. – 85 × 3. – 43 × 31.96 in) (W × H × D) – Without mounting ears: 435 × 87 × 780 mm (17. – 13 × 3. – 43 × 30.71 in) (W × H × D)
Weight	Gross weight (with all drives loaded) < 37.5 kg (82.67 lbs)
Operating Temperature	5°C ‒ 45°C (41°F ‒ 113°F)

Overview

The Inspur NF5280R6 is a 2U rack server rack server. It is configured with 1 or 2 Ampere ® Altra ® / Altra Max ® processors: Up to 80 cores (3.3 GHz)/128 cores (3.0 GHz). Memory: 1. Up to 32 DIMMs.

Key Features

Processor: – 1 or 2 Ampere ® Altra ® / Altra Max ® processors: Up to 80 cores (3.3 GHz)/128 cores (3.0 GHz)
– 2 groups of x16 CCIX links, up to 25 GT/s per link TDP up to 250 W
Memory: – 1. Up to 32 DIMMs
– 2. 8 memory channels per processor, and up to 2 memory slots per channel
– 3. Up to 3200 MT/s
– 4. RDIMMs supported
– 5. ECC, memory mirroring and memory rank sparing
Storage: – Front Drive
– 12 x 3.5″ or 2.5″ hot-SWap SATA/SAS/NVMe drives
– Rear Drive
– 4 x 2.5″ hot-SWap SATA/SAS/NVMe SSD drives
– Onboard Drive
– (optional) 1 x onboard NVMe M.2
– Up to 1 BMC TF Card
Network: – 1 optional OCP NIC 3.0 module (10 Gb/s, 25 Gb/s, 40 Gb/s, and 100 Gb/s)
– Standard PCIe form factor: 1/10/25/40/100G NIC
I/O Expansion: – Up to 8 PCIe slots(Altra: 4* x16 +4* x8, Altra max:6* x16+2* x8)
– 1 OCP 3.0 (Altra supports x8x8 multi-host, Altra max supports x16 single-host or x8x8 multi-host)
Power Supply: – 800/1300/1600/2000 W CRPS standard PSUs with 1+1 redundancy
– 110 VAC ‒ 230 VAC: 90 V ‒ 264 V
– 240 VDC: 180 V ‒ 320 V
Cooling: 4 hot-swap 8056 fans with N+1 redundancy
System Management: Integrated with 1 independent 1000 Mbps network port, dedicated for IPMI remote management

Configuration, availability and lead time depend on the required quantity, system pairing and delivery destination. Send your requirement to receive a quotation.
