Lenovo ThinkSystem ST650 V3

The Lenovo ThinkSystem ST650 V3 is a Tower or 4U Rack server from Lenovo, powered by 5th Gen or 4th Gen Intel Xeon Scalable processors, with 2.5-inch drive bays.

SKU: ST650-V3 Category: Server Brand: Lenovo

Technical Specifications
Overview

Product SKU	ST650-V3
Form factor	Tower or 4U rack
Processor	One or two Intel Xeon Scalable CPUs, 4th Gen (Sapphire Rapids) or 5th Gen (Emerald Rapids).
Processor cores	Up to 32 cores per CPU; up to 64 cores with two CPUs.
Processor speed	Up to 3.9 GHz.
Processor power	Up to 250 W TDP per CPU.
Chipset	Intel C741 "Emmitsburg" chipset (Eagle Stream platform).
Memory slots	32 DIMM slots, 16 per CPU; 8 memory channels per CPU, 2 DIMMs per channel (DPC).
Memory type	DDR5 (TruDDR5) RDIMM, 9×4 RDIMM and 3DS RDIMM.
Maximum memory	4 TB using 32 x 128 GB 3DS RDIMMs; 2 TB with a single CPU.
Memory speed	4800 MHz at 1 DIMM per channel; 4400 MHz at 2 DIMMs per channel.
Memory protection	ECC, SDDC and ADDDC (ADDDC requires Platinum or Gold processors), memory mirroring.
Persistent memory	Not supported.
Drive bays	2.5-inch: up to 32 hot-swap bays (24 NVMe), plus 2 x 5.25-inch media bays. 3.5-inch: up to 16 hot-swap bays (16 NVMe), no media bays; or up to 12 hot-swap bays (12 NVMe) plus 2 x 5.25-inch media bays. Internal: M.2 module supporting up to two M.2 drives.
Media bays	2 x 5.25-inch half-height bays, available in most configurations; supports two of LTO tape, RDX or slim DVD-RW.
Maximum internal storage	2.5-inch: 983.04 TB (32 x 30.72 TB SAS/SATA SSD), 368.64 TB (24 x 15.36 TB NVMe SSD), 76.8 TB (32 x 2.4 TB HDD). 3.5-inch: 352 TB (16 x 22 TB HDD), 245.76 TB (16 x 15.36 TB SAS/SATA SSD), 61.44 TB (16 x 3.84 TB NVMe SSD).
Storage controller	8 onboard SATA ports (Intel VROC SATA RAID, formerly Intel RSTe RAID). Up to 12 onboard NVMe ports (Intel VROC NVMe RAID; licence required for non-Intel NVMe SSDs). NVMe Retimer Adapter (Intel VROC NVMe RAID). 12 Gb SAS/SATA RAID adapters: 8, 16 or 32 ports, up to 8 GB flash-backed cache, PCIe 4.0 or 3.0 host interface. 12 Gb SAS/SATA HBA (non-RAID): 8 or 16 ports, PCIe 4.0 or 3.0 host interface.
PCIe slots	9 slots, all on the system board: 5 x PCIe 5.0 and 4 x PCIe 4.0. Slots 1-8 full-height full-length (FHFL); slot 9 full-height half-length (FHHL). Slots 4-8 require CPU 2. Slot 1: PCIe 5.0 x16 (CPU 1) Slot 2: PCIe 5.0 x8 (CPU 1) Slot 3: PCIe 5.0 x16 (CPU 1) Slot 4: PCIe 5.0 x8 (CPU 1) Slot 5: PCIe 5.0 x16 (CPU 2) Slot 6: PCIe 4.0 x8 (CPU 2) Slot 7: PCIe 4.0 x16 (CPU 2) Slot 8: PCIe 4.0 x8 (CPU 2) Slot 9: PCIe 4.0 x8 (CPU 1) A RAID adapter or HBA can be fitted in a dedicated area that does not consume a PCIe slot.
Maximum GPU	Up to 8 single-wide or 4 double-wide GPUs.
Network	2 x 10GBASE-T Ethernet RJ45 (Broadcom BCM57416); 1 dedicated Gigabit port for XClarity Controller remote management.
Ports	Front: 1 x USB 3.2 G1 (5 Gb/s), 1 x USB 2.0 (also for XCC local management). Rear: 2 x 10GBASE-T RJ45, 4 x USB 3.2 G1 (5 Gb/s), 1 x VGA, 1 x DB-9 COM serial, 1 x 1GbE RJ-45 systems management, external diagnostics port. Internal: 2 x USB 3.2 G1 connectors for operating system or licence key.
Cooling	Up to 4 x 92 mm hot-swap fans, single-rotor or dual-rotor, configuration dependent; N+1 redundant. One additional fan integrated in each power supply.
Power supply	Up to two hot-swap redundant AC supplies: 750 W, 1100 W, 1800 W, 2600 W. 220 V AC input; 750 W and 1100 W also support 110 V. 80 PLUS Platinum or 80 PLUS Titanium. China only: 240 V DC on all options.
Security	Power-on password, administrator password, Root of Trust module supporting TPM 2.0 and Platform Firmware Resiliency (PFR). Optional lockable front security door and chassis intrusion switch. China only: Nationz TPM 2.0.
System management	Operator panel with status LEDs. XClarity Controller 2 (XCC2). XClarity One, XClarity Integrator plugins, XClarity Energy Manager. Optional External Diagnostics Handset with LCD and XClarity Controller Platinum.
Operating systems	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi.
Warranty	Three-year or one-year (model dependent) customer-replaceable unit and onsite limited warranty with 9×5 next business day (NBD).
Dimensions (H x W x D)	Height 462 mm (18.2 in.), width 175 mm (6.9 in.), depth 734 mm (28.9 in.).
Weight	39.1 kg (86.2 lb) maximum.

Overview

The Lenovo ThinkSystem ST650 V3 is a Lenovo server platform, with One or two Intel Xeon Scalable CPUs, 4th Gen (Sapphire Rapids) or 5th Gen (Emerald Rapids)., aimed at server platform workloads. Its full parameter set is listed below.

At a glance

Product SKU: ST650-V3
Form factor: Tower or 4U rack
Processor: One or two Intel Xeon Scalable CPUs, 4th Gen (Sapphire Rapids) or 5th Gen (Emerald Rapids).
Processor cores: Up to 32 cores per CPU; up to 64 cores with two CPUs.
Processor speed: Up to 3.9 GHz.
Processor power: Up to 250 W TDP per CPU.
Chipset: Intel C741 "Emmitsburg" chipset (Eagle Stream platform).
Memory slots: 32 DIMM slots, 16 per CPU; 8 memory channels per CPU, 2 DIMMs per channel (DPC).
Memory type: DDR5 (TruDDR5) RDIMM, 9×4 RDIMM and 3DS RDIMM.
Maximum memory: 4 TB using 32 x 128 GB 3DS RDIMMs; 2 TB with a single CPU.
Memory speed: 4800 MHz at 1 DIMM per channel; 4400 MHz at 2 DIMMs per channel.
Memory protection: ECC, SDDC and ADDDC (ADDDC requires Platinum or Gold processors), memory mirroring.
Persistent memory: Not supported.
Drive bays: 2.5-inch: up to 32 hot-swap bays (24 NVMe), plus 2 x 5.25-inch media bays. 3.5-inch: up to 16 hot-swap bays (16 NVMe), no media bays; or up to 12 hot-swap bays (12 NVMe) plus 2 x 5.25-inch media bays. Internal: M.2 module supporting up to two M.2 drives.
Media bays: 2 x 5.25-inch half-height bays, available in most configurations; supports two of LTO tape, RDX or slim DVD-RW.
Maximum internal storage: 2.5-inch: 983.04 TB (32 x 30.72 TB SAS/SATA SSD), 368.64 TB (24 x 15.36 TB NVMe SSD), 76.8 TB (32 x 2.4 TB HDD). 3.5-inch: 352 TB (16 x 22 TB HDD), 245.76 TB (16 x 15.36 TB SAS/SATA SSD), 61.44 TB (16 x 3.84 TB NVMe SSD).
Storage controller: 8 onboard SATA ports (Intel VROC SATA RAID, formerly Intel RSTe RAID). Up to 12 onboard NVMe ports (Intel VROC NVMe RAID; licence required for non-Intel NVMe SSDs). NVMe Retimer Adapter (Intel VROC NVMe RAID). 12 Gb SAS/SATA RAID adapters: 8, 16 or 32 ports, up to 8 GB flash-backed cache, PCIe 4.0 or 3.0 host interface. 12 Gb SAS/SATA HBA (non-RAID): 8 or 16 ports, PCIe 4.0 or 3.0 host interface.
PCIe slots: 9 slots, all on the system board: 5 x PCIe 5.0 and 4 x PCIe 4.0. Slots 1-8 full-height full-length (FHFL); slot 9 full-height half-length (FHHL). Slots 4-8 require CPU 2. Slot 1: PCIe 5.0 x16 (CPU 1) Slot 2: PCIe 5.0 x8 (CPU 1) Slot 3: PCIe 5.0 x16 (CPU 1) Slot 4: PCIe 5.0 x8 (CPU 1) Slot 5: PCIe 5.0 x16 (CPU 2) Slot 6: PCIe 4.0 x8 (CPU 2) Slot 7: PCIe 4.0 x16 (CPU 2) Slot 8: PCIe 4.0 x8 (CPU 2) Slot 9: PCIe 4.0 x8 (CPU 1) A RAID adapter or HBA can be fitted in a dedicated area that does not consume a PCIe slot.
Maximum GPU: Up to 8 single-wide or 4 double-wide GPUs.
Network: 2 x 10GBASE-T Ethernet RJ45 (Broadcom BCM57416); 1 dedicated Gigabit port for XClarity Controller remote management.
Ports: Front: 1 x USB 3.2 G1 (5 Gb/s), 1 x USB 2.0 (also for XCC local management). Rear: 2 x 10GBASE-T RJ45, 4 x USB 3.2 G1 (5 Gb/s), 1 x VGA, 1 x DB-9 COM serial, 1 x 1GbE RJ-45 systems management, external diagnostics port. Internal: 2 x USB 3.2 G1 connectors for operating system or licence key.
Cooling: Up to 4 x 92 mm hot-swap fans, single-rotor or dual-rotor, configuration dependent; N+1 redundant. One additional fan integrated in each power supply.
Power supply: Up to two hot-swap redundant AC supplies: 750 W, 1100 W, 1800 W, 2600 W. 220 V AC input; 750 W and 1100 W also support 110 V. 80 PLUS Platinum or 80 PLUS Titanium. China only: 240 V DC on all options.
Security: Power-on password, administrator password, Root of Trust module supporting TPM 2.0 and Platform Firmware Resiliency (PFR). Optional lockable front security door and chassis intrusion switch. China only: Nationz TPM 2.0.
System management: Operator panel with status LEDs. XClarity Controller 2 (XCC2). XClarity One, XClarity Integrator plugins, XClarity Energy Manager. Optional External Diagnostics Handset with LCD and XClarity Controller Platinum.
Operating systems: Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi.
Warranty: Three-year or one-year (model dependent) customer-replaceable unit and onsite limited warranty with 9×5 next business day (NBD).
Dimensions (H x W x D): Height 462 mm (18.2 in.), width 175 mm (6.9 in.), depth 734 mm (28.9 in.).
Weight: 39.1 kg (86.2 lb) maximum.

When to choose this server platform

Choose it for server platform workloads..

Reading the specifications

See the grouped parameters above for capacity, connectivity, power and physical data; confirm the specific configuration against your workload before ordering.

Platform & compatibility

Supports processor One or two Intel Xeon Scalable CPUs, 4th Gen (Sapphire Rapids) or 5th Gen (Emerald Rapids)., network 2 x 10GBASE-T Ethernet RJ45 (Broadcom BCM57416); 1 dedicated Gigabit port for XClarity Controller remote…. Confirm CPU/controller, memory, drives and power against your environment before ordering.

Deployment notes

The Lenovo ThinkSystem ST650 V3 is supplied as a configured platform. Send the required configuration for a firm quote.

FAQ

What processors/controllers does it use? One or two Intel Xeon Scalable CPUs, 4th Gen (Sapphire Rapids) or 5th Gen (Emerald Rapids)..

How do I get pricing? Send the required configuration; quotes depend on quantity, options and destination.

Configuration, availability and lead time depend on the required quantity, configuration and delivery destination. Send your requirement to receive a quotation.
