FusionServer 1158H V7

FusionServer 1158H V7 (1158H V7) is a new-generation 1U 1-socket rack server designed for the Internet, Internet Data Center (IDC), cloud computing, enterprise business, and telecom. The 1158H V7 is ideal for IT core services, virtualization, high-performance computing (HPC), and other complex workloads. The 1158H V7 features low power consumption, high scalability and reliability, easy deployment, and simplified management.

SKU: XFUSION-FUSIONSERVER-1158H-V7 Category: Server Brand: xFusion

Technical Specifications
Overview

Form Factor	1U rack server
Processor	1 x 4th Gen AMD® EPYC™ 9004 Series processor (Genoa), up to 400 W TDP
Memory	24 x DDR5 DIMMs, up to 4800 MT/s
Local Storage	– 10 x 2.5″ drives (up to 4 x NVMe SSDs and 8 x SAS/SATA drives, total ≤ 10) – 10 x 2.5″ drives (up to 10 x NVMe SSDs, 8 x SAS/SATA drives, total ≤ 10) – 2 x M.2 SSDs (SATA/NVMe)
RAID	Optional RAID 0, 1, 10, 5, 50, 6, or 60 with cache supercapacitor protection; RAID level migration, drive roaming, self-diagnosis, and Web-based remote configuration
Network	Supports multiple network expansion capabilities; 2 x OCP 3.0 NICs, configurable on demand; hot swap and PCIe 5.0 supported
PCle Expansion	5 x PCIe expansion slots, including 2 x FlexIO slots dedicated for OCP 3.0 NICs and 3 x standard PCIe slots, supporting PCIe 5.0
Fan	8 x hot-swappable counter-rotating fans, N+1 redundancy
PSU	900 W Platinum/Titanium hot-swappable PSU, 1500 W/2000 W Platinum PSUs, 1+1 redundancy
Management	– The iBMC chip integrates one dedicated management GE network port, providing comprehensive management features such as fault diagnosis, automated O&M, and hardware security hardening. – The iBMC supports standard interfaces such as Redfish, SNMP, and IPMI 2.0; provides a remote management interface based on HTML5/VNC KVM; supports out-of-band management functions such as monitoring, diagnosis, configuration, Agentless, and remote control, simplifying management complexity. – Optional FusionDirector management software provides advanced management features such as five intelligent technologies, enabling intelligent, automated, visualized, and refined management throughout the lifecycle.
OS	xFusion FusionOS, Microsoft Windows Server, SUSE Linux Enterprise Server, VMware ESXi, Red Hat Enterprise Linux, CentOS, Oracle, Ubuntu, Debian, openEuler, etc.
Security	Power-on password, administrator password, TPM 2.0*, security panel, secure boot, and cover opening detection
Operating Temperature	5°C to 40°C (41°F to 104°F), compliant with ASHRAE Class A1/A2/A3
Certification	CE, UL, CCC, FCC, VCCI, RoHS, etc.
Installation Suite	L-shaped guide rails, retractable guide rails, and holding rails
Dimensions (H x W x D)	2.5″ drive chassis: 43.5 mm x 447 mm x 798 mm

Overview

The FusionServer 1158H V7 is an enterprise server in a 1U chassis, configured for virtualisation, databases and general enterprise workloads. Its processor, memory, storage, networking and expansion options are summarised below.

At a glance

Form Factor: 1U rack server
Processor: 1 x 4th Gen AMD® EPYC™ 9004 Series processor (Genoa), up to 400 W TDP
Memory: 24 x DDR5 DIMMs, up to 4800 MT/s
Local Storage: – 10 x 2.5″ drives (up to 4 x NVMe SSDs and 8 x SAS/SATA drives, total ≤ 10) – 10 x 2.5″ drives (up to 10 x NVMe SSDs, 8 x SAS/SATA drives, total ≤ 10) – 2 x M.2 SSDs (SATA/NVMe)
RAID: Optional RAID 0, 1, 10, 5, 50, 6, or 60 with cache supercapacitor protection; RAID level migration, drive roaming, self-diagnosis, and Web-based remote configuration
Network: Supports multiple network expansion capabilities; 2 x OCP 3.0 NICs, configurable on demand; hot swap and PCIe 5.0 supported
PCle Expansion: 5 x PCIe expansion slots, including 2 x FlexIO slots dedicated for OCP 3.0 NICs and 3 x standard PCIe slots, supporting PCIe 5.0
Fan: 8 x hot-swappable counter-rotating fans, N+1 redundancy
PSU: 900 W Platinum/Titanium hot-swappable PSU, 1500 W/2000 W Platinum PSUs, 1+1 redundancy
Management: – The iBMC chip integrates one dedicated management GE network port, providing comprehensive management features such as fault diagnosis, automated O&M, and hardware security hardening. – The iBMC supports standard interfaces such as Redfish, SNMP, and IPMI 2.0; provides a remote management interface based on HTML5/VNC KVM; supports out-of-band management functions such as monitoring, diagnosis, configuration, Agentless, and remote control, simplifying management complexity. – Optional FusionDirector management software provides advanced management features such as five intelligent…
OS: xFusion FusionOS, Microsoft Windows Server, SUSE Linux Enterprise Server, VMware ESXi, Red Hat Enterprise Linux, CentOS, Oracle, Ubuntu, Debian, openEuler, etc.
Security: Power-on password, administrator password, TPM 2.0*, security panel, secure boot, and cover opening detection
Operating Temperature: 5°C to 40°C (41°F to 104°F), compliant with ASHRAE Class A1/A2/A3
Certification: CE, UL, CCC, FCC, VCCI, RoHS, etc.
Installation Suite: L-shaped guide rails, retractable guide rails, and holding rails
Dimensions (H x W x D): 2.5″ drive chassis: 43.5 mm x 447 mm x 798 mm

When to choose this server

Choose this platform where the deployment needs virtualisation, databases and general enterprise workloads. It uses a 1U chassis and 900 W Platinum/Titanium hot-swappable PSU, 1500 W/2000 W Platinum PSUs, 1+1… power; local storage options include – 10 x 2.5″ drives (up to 4 x NVMe SSDs and 8 x SAS/SATA drives, total ≤ 10) – 10 x 2.5″….

Platform & compatibility

Supports processors: 1 x 4th Gen AMD® EPYC™ 9004 Series processor (Genoa), up to 400 W TDP, memory: 24 x DDR5 DIMMs, up to 4800 MT/s, network: Supports multiple network expansion capabilities; 2 x OCP 3.0 NICs, configurable on demand; hot swap and PCIe 5.0 supported, RAID: Optional RAID 0, 1, 10, 5, 50, 6, or 60 with cache supercapacitor protection;…, OS: xFusion FusionOS, Microsoft Windows Server, SUSE Linux Enterprise Server, VMware ESXi, Red Hat Enterprise Linux,…. Confirm the CPU, memory, drive and PSU configuration, plus rack rails, against your workload and rack before ordering.

Deployment notes

The FusionServer 1158H V7 is supplied as a configured platform; CPU, memory, storage and PSU are chosen at order time. out-of-band management: – The iBMC chip integrates one dedicated management GE network port, providing comprehensive management features such as fault diagnosis, automated…. power: 900 W Platinum/Titanium hot-swappable PSU, 1500 W/2000 W Platinum PSUs, 1+1 redundancy. network: Supports multiple network expansion capabilities; 2 x OCP 3.0 NICs, configurable on demand; hot swap and PCIe…. Rack rails, power distribution and cooling follow the 1U chassis class and are confirmed at order time. Send the required CPU, memory and drive mix for a firm configuration and quote.

FAQ

What processors does it support? 1 x 4th Gen AMD® EPYC™ 9004 Series processor (Genoa), up to 400 W TDP.

What memory does it take? 24 x DDR5 DIMMs, up to 4800 MT/s.

What drives does it accept? – 10 x 2.5″ drives (up to 4 x NVMe SSDs and 8 x SAS/SATA drives, total ≤ 10) – 10 x 2.5″ drives (up to 10 x NVMe SSDs, 8 x SAS/SATA drives, total ≤ 10) – 2 x M.2 SSDs (SATA/NVMe).

How is it managed? – The iBMC chip integrates one dedicated management GE network port, providing comprehensive management features such as fault diagnosis, automated O&M, and hardware security hardening. – The iBMC….

How do I get pricing? Send the required configuration; quotes depend on quantity, options and delivery destination.

Configuration, availability and lead time depend on the required quantity, server pairing and delivery destination. Send your requirement to receive a quotation.
