| Form Factor | 2U rack server |
|---|---|
| Processor | 1 or 2 x 4th or 5th Gen Intel® Xeon® Scalable processors with TDP up to 225 W per processor |
| Chipset | Emmitsburg PCH |
| Memory | 16 x DDR5 DIMMs, delivering up to 4800 MT/s speed |
| Local Storage | – 8 to 31 x 2.5″ SAS/SATA/SSD drives |
| RAID | Supports RAID 0, 1, 10, 1E, 5, 50, 6, or 60, optional supercapacitor for cache data power failure protection, RAID level migration, drive roaming, self-diagnosis, and remote web-based configuration |
| Network | Expansion capability for multiple types of networks |
| PCle Expansion | Up to 8 x PCIe slots |
| Heterogeneous Accelerator Card | Up to 4 x 75 W half-height half-length GPU accelerator cards |
| Fan | 4 x hot-swappable counter-rotating fans in N+1 redundancy |
| PSU | 900 W/1200 W/1500 W/2000 W/3000 W Platinum/Titanium hot-swappable PSUs in 1+1 redundancy |
| Management | – The iBMC chip integrates one dedicated management GE network port, providing comprehensive management features such as fault diagnosis, automatic O&M, and hardware security hardening. |
| OS | FusionOS, Microsoft Windows Server, SUSE Linux Enterprise Server, VMware ESXi, Red Hat Enterprise Linux, CentOS, Oracle, Ubuntu, Debian, and openEuler |
| Security | Power-on password, administrator password, Trusted Platform Module (TPM) 2.0, security bezel, secure boot, and chassis intrusion detection |
| Operating Temperature | 5ºC to 40ºC (41ºF to 104ºF), compliant with ASHRAE Classes A1, A2, A3, and A4 |
| Certification | CE, NRTL, CCC, FCC, VCCI, and RoHS |
| Installation Suite | L-shaped guide rails, adjustable guide rails, and holding rails |
| Dimensions (H x W x D) | Chassis with 3.5″ drives: 86.1 mm x 447 mm x 798 mm (3.39 in. x 17.60 in. x 31.42 in.) |
FusionServer 2288 V7
New-Generation 2U 2-Socket Rack Server
FusionServer 2288 V7 (2288 V7) is a new-generation 2U 2-socket rack server designed for the Internet, Internet Data Center (IDC), core IT services, cloud computing, virtualization, distributed storage, big data processing, enterprise or telecom service applications, and other complex workloads.
2288 V7 features low power consumption, high scalability and reliability, easy deployment, and simplified management.
Overview
The FusionServer 2288 V7 is an enterprise server in a 2U chassis, configured for virtualisation, databases and general enterprise workloads. Its processor, memory, storage, networking and expansion options are summarised below.
At a glance
- Form Factor: 2U rack server
- Processor: 1 or 2 x 4th or 5th Gen Intel® Xeon® Scalable processors with TDP up to 225 W per processor
- Chipset: Emmitsburg PCH
- Memory: 16 x DDR5 DIMMs, delivering up to 4800 MT/s speed
- Local Storage: – 8 to 31 x 2.5″ SAS/SATA/SSD drives – 10 to 14 x 3.5″ SAS/SATA drives – 4 x NVMe SSDs – Up to 31 x 2.5″ drives – Flash storage: 2 x M.2 SSDs
- RAID: Supports RAID 0, 1, 10, 1E, 5, 50, 6, or 60, optional supercapacitor for cache data power failure protection, RAID level migration, drive roaming, self-diagnosis, and remote web-based configuration
- Network: Expansion capability for multiple types of networks Supports OCP 3.0 NICs. One FlexIO card slot supports one OCP 3.0 NIC, which can be configured as required
- PCle Expansion: Up to 8 x PCIe slots 1 x FlexIO expansion slot dedicated for OCP 3.0, 1 x expansion slot dedicated for the RAID controller card, and 6 x standard PCIe expansion slots
- Heterogeneous Accelerator Card: Up to 4 x 75 W half-height half-length GPU accelerator cards
- Fan: 4 x hot-swappable counter-rotating fans in N+1 redundancy
- PSU: 900 W/1200 W/1500 W/2000 W/3000 W Platinum/Titanium hot-swappable PSUs in 1+1 redundancy
- Management: – The iBMC chip integrates one dedicated management GE network port, providing comprehensive management features such as fault diagnosis, automatic O&M, and hardware security hardening. – The iBMC supports standard interfaces such as Redfish, SNMP, and IPMI 2.0, provides a remote management interface based on HTML5/VNC KVM, and supports out-of-band management functions such as monitoring, diagnosis, configuration, Agentless, and remote control for simplified management. – It is optional to configure the FusionDirector management software that provides advanced management features such as five…
- OS: FusionOS, Microsoft Windows Server, SUSE Linux Enterprise Server, VMware ESXi, Red Hat Enterprise Linux, CentOS, Oracle, Ubuntu, Debian, and openEuler
- Security: Power-on password, administrator password, Trusted Platform Module (TPM) 2.0, security bezel, secure boot, and chassis intrusion detection
- Operating Temperature: 5ºC to 40ºC (41ºF to 104ºF), compliant with ASHRAE Classes A1, A2, A3, and A4
- Certification: CE, NRTL, CCC, FCC, VCCI, and RoHS
- Installation Suite: L-shaped guide rails, adjustable guide rails, and holding rails
- Dimensions (H x W x D): Chassis with 3.5″ drives: 86.1 mm x 447 mm x 798 mm (3.39 in. x 17.60 in. x 31.42 in.) Chassis with 2.5″ drives: 86.1 mm x 447 mm x 798 mm (3.39 in. x 17.60 in. x 31.42 in.)
When to choose this server
Choose this platform where the deployment needs virtualisation, databases and general enterprise workloads. It uses a 2U chassis and 900 W/1200 W/1500 W/2000 W/3000 W Platinum/Titanium hot-swappable PSUs in 1+1… power; local storage options include – 8 to 31 x 2.5″ SAS/SATA/SSD drives – 10 to 14 x 3.5″ SAS/SATA drives – 4 x NVMe SSDs –….
Platform & compatibility
Supports processors: 1 or 2 x 4th or 5th Gen Intel® Xeon® Scalable processors with TDP up to 225 W per processor, memory: 16 x DDR5 DIMMs, delivering up to 4800 MT/s speed, network: Expansion capability for multiple types of networks Supports OCP 3.0 NICs. One FlexIO card slot supports one OCP 3.0 NIC, which can be…, RAID: Supports RAID 0, 1, 10, 1E, 5, 50, 6, or 60, optional supercapacitor for cache…, OS: FusionOS, Microsoft Windows Server, SUSE Linux Enterprise Server, VMware ESXi, Red Hat Enterprise Linux, CentOS,…. Confirm the CPU, memory, drive and PSU configuration, plus rack rails, against your workload and rack before ordering.
Deployment notes
The FusionServer 2288 V7 is supplied as a configured platform; CPU, memory, storage and PSU are chosen at order time. out-of-band management: – The iBMC chip integrates one dedicated management GE network port, providing comprehensive management features such as fault diagnosis, automatic…. power: 900 W/1200 W/1500 W/2000 W/3000 W Platinum/Titanium hot-swappable PSUs in 1+1 redundancy. network: Expansion capability for multiple types of networks Supports OCP 3.0 NICs. One FlexIO card slot supports one…. Rack rails, power distribution and cooling follow the 2U chassis class and are confirmed at order time. Send the required CPU, memory and drive mix for a firm configuration and quote.
FAQ
What processors does it support? 1 or 2 x 4th or 5th Gen Intel® Xeon® Scalable processors with TDP up to 225 W per processor.
What memory does it take? 16 x DDR5 DIMMs, delivering up to 4800 MT/s speed.
What drives does it accept? – 8 to 31 x 2.5″ SAS/SATA/SSD drives – 10 to 14 x 3.5″ SAS/SATA drives – 4 x NVMe SSDs – Up to 31 x 2.5″ drives – Flash storage: 2 x M.2 SSDs.
How is it managed? – The iBMC chip integrates one dedicated management GE network port, providing comprehensive management features such as fault diagnosis, automatic O&M, and hardware security hardening. – The iBMC….
How do I get pricing? Send the required configuration; quotes depend on quantity, options and delivery destination.
