FusionServer 5288 V6

FusionServer 5288 V6 is a 4U 2-socket rack server that meets service requirements such as hot, warm, and cold data tiered deployment and historical data archiving. With its efficient design, FusionServer 5288 V6 ensures excellent computing performance and provides flexible and ultra-large local storage expansion capabilities, reducing data storage costs. The 5288 V6 can be configured with two Intel Xeon scalable processor, 32 DDR4 DIMMs, and 44 3.5-inch + 4 NVMe SSDs in a 4 U space. Integrates patented technologies such as DEMT intelligent power management and FDM intelligent fault management, and can be configured with FusionDirector full-lifecycle management software, effectively reducing OPEX and improving ROI.

SKU: XFUSION-FUSIONSERVER-5288-V6 Category: Server Brand: xFusion

Technical Specifications
Overview

Form Factor	4U Rack Server
Processor	1/2 x 3rd Gen Intel® Xeon® Scalable processors (Ice Lake, 8300/6300/5300/4300 series), up to 270 W TDP
Chipset	Intel® C621A
Memory	32 x DDR4 memory slots, up to 3200 MT/s; up to 16 x Intel® Optane™ Persistent Memory 200 Series, up to 3200 MT/s
Local Storage	– 36 to 44 x 3.5″ SAS/SATA HDDs and 4 x NVMe SSDs – 24 x 3.5″ SAS/SATA front hard disks – 4 x 3.5″ SAS/SATA internal hard disks – 16 x 3.5″ SAS/SATA hard disks and 4 x 2.5″ SAS/SATA/NVMe rear hard disks – 12 x 3.5″ SAS/SATA disks and 8 x 2.5″ rear hard disks (4 x 2.5″ HDDs + 4 x 2.5″ SAS/SATA/NVMe) – Flash storage: dual M.2 SSDs
RAID	Supports RAID 0, 1, 5, 50, 6, and 60, cache supercapacitor protection, RAID level migration, disk roaming, self-diagnosis, and web-based remote configuration
Network	OCP 3.0 NIC The two FLEX I/O card slots support two OCP 3.0 NICs, which can be configured as required Supports multiple OCP 3.0 NICs and hot swap
PCle Expansion	A maximum of 11 PCIe 4.0 slots, including one dedicated PCIe slot for the RAID controller card, two dedicated FLEX I/O slots for OCP 3.0, and eight standard PCIe 4.0 slots
Fan	4 hot-swappable fans, supporting N+1 redundancy
PSU	– 2 redundant hot-swappable PSUs in 1+1 redundancy mode; optional specifications: – 900 W AC Platinum/Titanium PSU (input: 100–240 V AC or 192–288 V DC) – 1500 W AC Platinum PSU: 1000 W (input: 100 V to 127 V AC); 1500 W (input: 200–240 V AC or 192–288 V DC) – 2000 W AC Platinum PSU: 1800 W (input: 200–220 V AC or 192–200 V DC); 2000 W (input: 220–240 V AC or 200–288 V DC)
Management	– The BMC chip integrates one dedicated management GE network port to provide comprehensive management features such as fault diagnosis, automatic O&M, and hardware security hardening. – The BMC supports standard interfaces such as Redfish, SNMP, and IPMI 2.0; provides a remote management interface based on HTML5/VNC KVM; supports out-of-band management functions such as monitoring, diagnosis, configuration, agentless, and remote control, simplifying management. – FusionDirector management software can be used to provide advanced management features such as five intelligent features, implementing intelligent, automatic, visualized, and refined management throughout the lifecycle.
OS	Microsoft Windows Server, SUSE Linux Enterprise Server, VMware ESXi, Red Hat Enterprise Linux, CentOS, Oracle Linux, Ubuntu, Debian, openEuler, etc.
Security	Power-on password, administrator password, TPM 2.0, security panel, secure boot, and cover opening detection
Operating Temperature	5°C to 45°C (41°F to 113°F), compliant with ASHRAE Class A1/A2/A3
Certification	CE, NRTL, CCC, FCC, VCCI, RoHS, etc.
Installation Suite	L-shaped guide rails, retractable guide rails, and holding rails
Dimensions (H x W x D)	Chassis: 175 mm x 447 mm x 790 mm

Overview

The FusionServer 5288 V6 is an enterprise server in a 4U chassis, configured for virtualisation, databases and general enterprise workloads. Its processor, memory, storage, networking and expansion options are summarised below.

At a glance

Form Factor: 4U Rack Server
Processor: 1/2 x 3rd Gen Intel® Xeon® Scalable processors (Ice Lake, 8300/6300/5300/4300 series), up to 270 W TDP
Chipset: Intel® C621A
Memory: 32 x DDR4 memory slots, up to 3200 MT/s; up to 16 x Intel® Optane™ Persistent Memory 200 Series, up to 3200 MT/s
Local Storage: – 36 to 44 x 3.5″ SAS/SATA HDDs and 4 x NVMe SSDs – 24 x 3.5″ SAS/SATA front hard disks – 4 x 3.5″ SAS/SATA internal hard disks – 16 x 3.5″ SAS/SATA hard disks and 4 x 2.5″ SAS/SATA/NVMe rear hard disks – 12 x 3.5″ SAS/SATA disks and 8 x 2.5″ rear hard disks (4 x 2.5″ HDDs + 4 x 2.5″ SAS/SATA/NVMe) – Flash storage: dual M.2 SSDs
RAID: Supports RAID 0, 1, 5, 50, 6, and 60, cache supercapacitor protection, RAID level migration, disk roaming, self-diagnosis, and web-based remote configuration
Network: OCP 3.0 NIC The two FLEX I/O card slots support two OCP 3.0 NICs, which can be configured as required Supports multiple OCP 3.0 NICs and hot swap
PCle Expansion: A maximum of 11 PCIe 4.0 slots, including one dedicated PCIe slot for the RAID controller card, two dedicated FLEX I/O slots for OCP 3.0, and eight standard PCIe 4.0 slots
Fan: 4 hot-swappable fans, supporting N+1 redundancy
PSU: – 2 redundant hot-swappable PSUs in 1+1 redundancy mode; optional specifications: – 900 W AC Platinum/Titanium PSU (input: 100–240 V AC or 192–288 V DC) – 1500 W AC Platinum PSU: 1000 W (input: 100 V to 127 V AC); 1500 W (input: 200–240 V AC or 192–288 V DC) – 2000 W AC Platinum PSU: 1800 W (input: 200–220 V AC or 192–200 V DC); 2000 W (input: 220–240 V AC or 200–288 V DC)
Management: – The BMC chip integrates one dedicated management GE network port to provide comprehensive management features such as fault diagnosis, automatic O&M, and hardware security hardening. – The BMC supports standard interfaces such as Redfish, SNMP, and IPMI 2.0; provides a remote management interface based on HTML5/VNC KVM; supports out-of-band management functions such as monitoring, diagnosis, configuration, agentless, and remote control, simplifying management. – FusionDirector management software can be used to provide advanced management features such as five intelligent features,…
OS: Microsoft Windows Server, SUSE Linux Enterprise Server, VMware ESXi, Red Hat Enterprise Linux, CentOS, Oracle Linux, Ubuntu, Debian, openEuler, etc.
Security: Power-on password, administrator password, TPM 2.0, security panel, secure boot, and cover opening detection
Operating Temperature: 5°C to 45°C (41°F to 113°F), compliant with ASHRAE Class A1/A2/A3
Certification: CE, NRTL, CCC, FCC, VCCI, RoHS, etc.
Installation Suite: L-shaped guide rails, retractable guide rails, and holding rails
Dimensions (H x W x D): Chassis: 175 mm x 447 mm x 790 mm

When to choose this server

Choose this platform where the deployment needs virtualisation, databases and general enterprise workloads. It uses a 4U chassis and – 2 redundant hot-swappable PSUs in 1+1 redundancy mode; optional… power; local storage options include – 36 to 44 x 3.5″ SAS/SATA HDDs and 4 x NVMe SSDs – 24 x 3.5″ SAS/SATA front hard disks –….

Platform & compatibility

Supports processors: 1/2 x 3rd Gen Intel® Xeon® Scalable processors (Ice Lake, 8300/6300/5300/4300 series), up to 270 W TDP, memory: 32 x DDR4 memory slots, up to 3200 MT/s; up to 16 x Intel® Optane™ Persistent Memory 200 Series, up to 3200 MT/s, network: OCP 3.0 NIC The two FLEX I/O card slots support two OCP 3.0 NICs, which can be configured as required Supports multiple OCP 3.0 NICs and…, RAID: Supports RAID 0, 1, 5, 50, 6, and 60, cache supercapacitor protection, RAID…, OS: Microsoft Windows Server, SUSE Linux Enterprise Server, VMware ESXi, Red Hat Enterprise Linux, CentOS, Oracle Linux,…. Confirm the CPU, memory, drive and PSU configuration, plus rack rails, against your workload and rack before ordering.

Deployment notes

The FusionServer 5288 V6 is supplied as a configured platform; CPU, memory, storage and PSU are chosen at order time. out-of-band management: – The BMC chip integrates one dedicated management GE network port to provide comprehensive management features such as fault diagnosis, automatic…. power: – 2 redundant hot-swappable PSUs in 1+1 redundancy mode; optional specifications: – 900 W…. network: OCP 3.0 NIC The two FLEX I/O card slots support two OCP 3.0 NICs, which can be configured as required…. Rack rails, power distribution and cooling follow the 4U chassis class and are confirmed at order time. Send the required CPU, memory and drive mix for a firm configuration and quote.

FAQ

What processors does it support? 1/2 x 3rd Gen Intel® Xeon® Scalable processors (Ice Lake, 8300/6300/5300/4300 series), up to 270 W TDP.

What memory does it take? 32 x DDR4 memory slots, up to 3200 MT/s; up to 16 x Intel® Optane™ Persistent Memory 200 Series, up to 3200 MT/s.

What drives does it accept? – 36 to 44 x 3.5″ SAS/SATA HDDs and 4 x NVMe SSDs – 24 x 3.5″ SAS/SATA front hard disks – 4 x 3.5″ SAS/SATA internal hard disks – 16 x 3.5″ SAS/SATA hard disks and 4 x 2.5″ SAS/SATA/NVMe rear hard disks – 12 x 3.5″….

How is it managed? – The BMC chip integrates one dedicated management GE network port to provide comprehensive management features such as fault diagnosis, automatic O&M, and hardware security hardening. – The BMC….

How do I get pricing? Send the required configuration; quotes depend on quantity, options and delivery destination.

Configuration, availability and lead time depend on the required quantity, server pairing and delivery destination. Send your requirement to receive a quotation.
