| Capacity | Usable Capacity: Up to 768 TB, 681 TiB |
|---|---|
| Networking | Built-In Networking: Required Networking (rNDC or OCP): Optional Networking with I/O Cards: |
| Physical | Full Weight: 9 SSDs: 34 kg / 75 lbs |
| Power | Power 100-120/200-240v~, 50/60 Hz: 9 SSDs: 735 VA |
| Regulatory | Statement of Compliance Detailed regulatory information and verification of compliance is available at the Dell Regulatory Compliance website. |
| Storage Devices | Storage Shelves |
PowerProtect Data Domain DD9410 backup appliance
PowerProtect Data Domain DD9410 backup appliance.High-performance enterprise protection storage built for cyber resilience – across on-premises and multicloud environments. Built on the Data Domain Platform, this backup appliance delivers trusted data services for faster recovery.
Overview
The PowerProtect Data Domain DD9410 backup appliance is an enterprise backup storage. It is built for enterprise backup storage workloads.
At a glance
- Capacity: Usable Capacity: Up to 768 TB, 681 TiB Usable Capacity W/ Cloud Tier: Up to 2.3 PB, 2.0 PiB Logical Capacity: Up to 57.6 PB Logical Capacity: W/ Cloud Tier: Up to 149.8 PB
- Networking: Built-In Networking: 1x Management port 2x LOM Required Networking (rNDC or OCP): 4x 10G BASE-T 4x 10/25G SFP+ Optional Networking with I/O Cards: Up to 4 10G Base-T cards that can auto-negotiate down to support 1GbE Up to four quad port 10/25G SFP28 Up to four dual port 100G QSFP Up to four quad port 32Gb FC HBA
- Physical: Full Weight: 9 SSDs: 34 kg / 75 lbs Width: 43.43 cm / 17.1 in Height: 8.63 cm / 3.4 in Depth: 72.39 cm / 28.5 in 2U EIA rack units
- Power: Power 100-120/200-240v~, 50/60 Hz: 9 SSDs: 735 VA Thermal Rating (Watts): 9 SSDs : 694 Watts Thermal Rating (BTU/hr): 9 SSDs : 2369 btu/hr Operating Temperature/Altitude*: 10°C to 35°C, 35°C 2,953 ft Non-Operating (Transportation) Temperature: -40°C to +65°C (-40°F to +149°F) Operating Humidity: 10% to 80% with 29°C (84.2°F) maximum dew point Operation Acoustic Noise (Sound Power): LWAd: 8.7 bels Operation Acoustic Noise (Sound Pressure): LpAm: 76 db
- Regulatory: Statement of Compliance Dell Information Technology Equipment is compliant with all currently applicable regulatory requirements for Electromagnetic Compatibility, Product Safety, and Environmental Regulations where placed on market. Detailed regulatory information and verification of compliance is available at the Dell Regulatory Compliance website.
- Storage Devices: Storage Shelves DS600 SHELF : SAS FS240 SHELF: SSD
When to choose this storage system
Choose it for enterprise backup storage workloads..
Reading the specifications
capacity and controller count set the usable scale and performance headroom.
Platform & compatibility
Supplied as a complete storage system. Confirm the host protocols, capacity and controller configuration for your environment before ordering.
Deployment notes
The PowerProtect Data Domain DD9410 backup appliance is supplied as a configured system; capacity, controllers and licensing are selected at order time. Availability, firmware and licensing are confirmed against the current release at order time. Send the required capacity, protocol and performance target for a firm configuration and quote.
FAQ
How do I get pricing? Send the required capacity and topology; quotes depend on quantity, options and destination.
