| Product SKU | DE4200H 2U12 LFF |
|---|---|
| Form Factor | : 2U rack mount. |
| Controller Memory | 64GB per system (32GB per controller) |
| Drive Bays | 12 drive bays |
| Maximum Drives | 96 HDDs / 24 SSDs |
| Maximum Raw Capacity | 2.1PB maximum raw capacity |
| Shelf Support | DE120S, DE240S |
| Controller (per System) | 2 |
| Standard Cache (per System) | 64 GB |
| Maximum Cache (per System) | 64 GB |
| Standard Host Port Type | 32Gb FC |
| Standard Host Port Quantity (per System) | 12 |
| Optional Host Ports(must Select One) | N/A* |
| 12 GB SAS (Port Quantity Per System) | 8 |
| Management | RJ45 |
| Expansion Port Type | x4 SAS |
| Standard Expansion Port Quantity (per System) | 4 |
| Maximum Expansion Enclosures Per Control Enclosure | 3, 3 |
| Supported Expansion Enclosures | 7Y63, 7Y68 |
| Maximum HDDs Per System (System = Controller Plus Expansion Enclosures) | 84 |
| RAID Levels | RAID 0, 1, 3, 5, 6 and 10; Dynamic Disk Pools. |
| Controller System Memory | 64 GB per system (32 GB per controller). Cache mirroring between the controllers. Flash-backed cache protection (includes battery for destaging to flash). |
| Expansion Enclosure Support | • Expansion enclosures may be mixed up to a maximum of 3 expansion enclosures |
| Drive Expansion Connectivity | • 4x 12 Gb SAS x4 (Mini-SAS HD SFF-8644) expansion ports on each enclosure (2x ports on each controller) for the attachment to the expansion enclosures. |
| Storage Capacity | Up to 24 LFF / SFF SSDs. |
| Host Operating Systems | Microsoft Windows Server; Red Hat Enterprise Linux (RHEL); SUSE Linux Enterprise Server (SLES); VMware vSphere. |
| Configuration Maximums | • Maximum storage capacity: 1.47 PB |
| Cooling | Fans that are built into power supplies (2U24 SFF and 2U12 LFF). |
| Power Supply | Two redundant hot-swap 913 W (100 – 240 V) (2U24 and 2U12 enclosures) Platinum AC power supplies. |
| Management Ports | • 1x 1 GbE port (UTP, RJ-45) per controller for out-of-band management. |
| Management Interfaces | System Manager web-based GUI; SAN Manager standalone GUI; Serial console ASCII menu, SNMP, email, and syslog alerts; optional Lenovo XClarity. |
| Security Features | Secure Socket Layer (SSL), user level security, role-based access control (RBAC), LDAP authentication. |
| Warranty and Support | Three-year customer-replaceable unit and onsite limited warranty with 9×5 next business day (NBD) parts delivered. Also available are 9×5 NBD onsite response, 24×7 coverage with 2-hour or 4-hour onsite response, or 6-hour or 24-hour committed repair (select areas), YourDrive YourData, Premier Support, and 1-year or 2-year post-warranty extensions. |
| Dimensions (H x W x D) | 2U12 LFF enclosure: |
| Weight | • DE4200H 2U12 LFF controller enclosure (7DCA): 28.98 kg (63.9 lb) |
Storage
Lenovo ThinkSystem DE4200H 2U12 Hybrid Flash Array
The Lenovo ThinkSystem DE4200H 2U12 Hybrid Flash Array is a : 2U rack mount storage system from Lenovo.
Overview
The Lenovo ThinkSystem DE4200H 2U12 Hybrid Flash Array is a Lenovo storage system in a 2U rack mount. and 64GB per system (32GB per controller), aimed at storage system workloads. Its full parameter set is listed below.
At a glance
- Product SKU: DE4200H 2U12 LFF
- Form Factor: 2U rack mount.
- Controller Memory: 64GB per system (32GB per controller)
- Drive Bays: 12 drive bays
- Maximum Drives: 96 HDDs / 24 SSDs
- Maximum Raw Capacity: 2.1PB maximum raw capacity
- Shelf Support: DE120S, DE240S
- Controller (per System): 2
- Standard Cache (per System): 64 GB
- Maximum Cache (per System): 64 GB
- Standard Host Port Type: 32Gb FC
- Standard Host Port Quantity (per System): 12
- Optional Host Ports(must Select One): N/A*
- 12 GB SAS (Port Quantity Per System): 8
- Management: RJ45 2
- Expansion Port Type: x4 SAS
- Standard Expansion Port Quantity (per System): 4
- Maximum Expansion Enclosures Per Control Enclosure: 3, 3
- Supported Expansion Enclosures: 7Y63, 7Y68
- Maximum HDDs Per System (System = Controller Plus Expansion Enclosures): 84
- RAID Levels: RAID 0, 1, 3, 5, 6 and 10; Dynamic Disk Pools. ; RAID 3 can be configured only through the Storage Manager Command Line (SMcli). ; RAID 6, minimum six drives are required (five drives with one hot spare) for system functionality and data storage.
- Controller System Memory: 64 GB per system (32 GB per controller). Cache mirroring between the controllers. Flash-backed cache protection (includes battery for destaging to flash).
- Expansion Enclosure Support: Expansion enclosures may be mixed up to a maximum of 3 expansion enclosures
- Drive Expansion Connectivity: 4x 12 Gb SAS x4 (Mini-SAS HD SFF-8644) expansion ports on each enclosure (2x ports on each controller) for the attachment to the expansion enclosures.
- Storage Capacity: Up to 24 LFF / SFF SSDs.
- Host Operating Systems: Microsoft Windows Server; Red Hat Enterprise Linux (RHEL); SUSE Linux Enterprise Server (SLES); VMware vSphere.
- Configuration Maximums: Maximum storage capacity: 1.47 PB ; Maximum number of logical volumes: 512 ; Maximum number of drives in a RAID volume group: – RAID 0, 1/10: 192 – RAID 3, 5, 6: 30 ; Maximum SSD read cache size: ; Maximum number of hosts: 256 ; Maximum number of snapshots: 512 (requires an optional license) ; Maximum number of mirroring pairs: 32 (requires an optional license)
- Cooling: Fans that are built into power supplies (2U24 SFF and 2U12 LFF).
- Power Supply: Two redundant hot-swap 913 W (100 – 240 V) (2U24 and 2U12 enclosures) Platinum AC power supplies.
- Management Ports: 1x 1 GbE port (UTP, RJ-45) per controller for out-of-band management. ; 2x Serial console ports (RJ-45 and USB-C) for system configuration. ; In-band management via I/O path.
- Management Interfaces: System Manager web-based GUI; SAN Manager standalone GUI; Serial console ASCII menu, SNMP, email, and syslog alerts; optional Lenovo XClarity.
- Security Features: Secure Socket Layer (SSL), user level security, role-based access control (RBAC), LDAP authentication.
- Warranty and Support: Three-year customer-replaceable unit and onsite limited warranty with 9×5 next business day (NBD) parts delivered. Also available are 9×5 NBD onsite response, 24×7 coverage with 2-hour or 4-hour onsite response, or 6-hour or 24-hour committed repair (select areas), YourDrive YourData, Premier Support, and 1-year or 2-year post-warranty extensions.
- Dimensions (H x W x D): 2U12 LFF enclosure: ; Height: 87 mm (3.4 in.) ; Width: 447 mm (17.6 in.) ; Depth: 536 mm (21.1 in.) 2U24 SFF enclosure: ; Height: 85 mm (3.3 in.) ; Width: 447 mm (17.6 in.) ; Depth: 511 mm (20.1 in.)
- Weight: DE4200H 2U12 LFF controller enclosure (7DCA): 28.98 kg (63.9 lb)
When to choose this storage system
Choose it for storage system workloads. A 2U rack mount. footprint with Two redundant hot-swap 913 W (100 – 240 V) (2U24 and 2U12 enclosures)… and 12 drive bays (RAID 0, 1, 3, 5, 6 and 10; Dynamic Disk Pools. ;…).
Reading the specifications
See the grouped parameters above for capacity, connectivity, power and physical data; confirm the specific configuration against your workload before ordering.
Platform & compatibility
Supports memory 64GB per system (32GB per controller), storage 12 drive bays. Confirm CPU/controller, memory, drives and power against your environment before ordering.
Deployment notes
The Lenovo ThinkSystem DE4200H 2U12 Hybrid Flash Array is supplied as a configured platform. management: RJ45 2. Send the required configuration for a firm quote.
FAQ
Memory/cache? 64GB per system (32GB per controller).
Storage options? 12 drive bays.
How do I get pricing? Send the required configuration; quotes depend on quantity, options and destination.
