Precision 7960 Rack Workstation

Overview

The Precision 7960 Rack puts a dual-socket Intel Xeon workstation into a 2U rack chassis, with up to 128 cores and up to 8 TB of DDR5 memory. Seven PCIe Gen4/Gen5 slots take up to two double-width professional graphics cards, eight M.2 NVMe drives handle local storage, and hot-swappable redundant power supplies with iDRAC management make it a data-centre-ready workstation.

Key Features

• Form Factor: 2U rack workstation
• Processor: Intel® Xeon® Platinum 8592+ 320MB Cache, 64 cores, 128 threads, 1.9 GHz to 3.9 GHz Turbo, 350W; Intel® Xeon® Platinum 8580 300MB Cache, 60 cores, 112 threads, 2.1 GHz to 4.0 GHz Turbo, 350W; Intel® Xeon® Platinum 8568Y+ 300MB Cache, 48 cores, 96 threads, 2.3 GHz to 4.0 GHz Turbo, 350W; Intel® Xeon® Platinum 8562Y+ 60MB Cache, 32 cores, 64 threads, 2.8 GHz to 4.1 GHz Turbo, 300W; Intel® Xeon® Gold 6548Y+ 60MB Cache, 32 cores, 64 threads, 2.5 GHz to 4.1 GHz Turbo, 250W; Intel® Xeon® Gold 6542Y 60MB Cache, 24 cores, 48 threads, 2.9 GHz to 4.1 GHz Turbo, 250W; Intel® Xeon® Gold 6534 22.5MB Cache, 8 cores, 16 threads, 3.9 GHz to 4.2 GHz Turbo, 195W; Intel® Xeon® Gold 6526Y 37.5MB Cache, 16 cores, 32 threads, 2.8 GHz to 3.9 GHz Turbo, 195W; Intel® Xeon® Silver 4514Y 30MB Cache, 16 cores, 32 threads, 2.0 GHz to 3.4 GHz Turbo, 150W; Intel® Xeon® Silver 4510 30MB Cache, 12 cores, 24 threads, 2.4 GHz to 4.1 GHz Turbo, 150W; Intel® Xeon® Silver 4509Y 22.5MB Cache, 8 cores, 16 threads, 2.6 GHz to 4.1 GHz Turbo, 125W; Intel® Xeon® Silver 4410Y, 30MB cache, 12 cores, 24 threads, 2.0GHz to 3.9GHz Turbo, 150W; Intel® Xeon® Gold 5415+, 22.5MB cache, 8 cores, 16 threads, 2.9GHz to 4.1GHz Turbo, 150W; Intel® Xeon® Silver 4416+, 37.5MB cache, 20 cores, 40 threads, 2.0GHz to 3.9GHz Turbo, 165W; Intel® Xeon® Gold 5418Y, 45MB Cache, 24 cores, 48 threads, 2.0GHz to 3.8GHz Turbo, 185W; Intel® Xeon® Gold 5420+, 52.5MB cache, 28 cores, 56 threads, 2.0GHz to 4.1GHz Turbo, 205W; Intel® Xeon® Gold 6430, 60MB cache, 32 cores, 64 threads, 2.1GHz to 3.4GHz Turbo, 270W; Intel® Xeon® Gold 6434, 22.5MB cache, 8 cores, 16 threads, 3.7 GHz to 4.1GHz Turbo, 195W; Intel® Xeon® Gold 6426Y, 37.5MB cache, 16 cores, 32 threads, 2.6GHz to 4.0GHz Turbo, 185W; Intel® Xeon® Gold 6442Y, 60MB cache, 24 cores, 48 threads, 2.5GHz to 4.0GHz Turbo, 185W; Intel® Xeon® Gold 6448Y, 60MB cache, 32 cores, 64 threads, 2.1GHz to 4.1GHz Turbo, 225W; Intel® Xeon® Gold 6444Y, 45MB cache, 16 cores, 32 threads, 3.6GHz to 4.0GHz Turbo, 270W; Intel® Xeon® Platinum 8452Y, 67.5MB cache, 36 cores, 72 threads, 2.0GHz to 3.2GHz Turbo, 300W; Intel® Xeon® Platinum 8460Y+, 105MB cache, 40 cores, 80 threads, 2.0GHz to 3.7GHz Turbo, 300W; Intel® Xeon® Platinum 8462Y+, 60MB cache, 32 cores, 64 threads, 2.8GHz to 4.1GHz Turbo, 300W; Intel® Xeon® Platinum 8468, 105MB cache, 48 cores, 96 threads, 2.1GHz to 3.8GHz Turbo, 350W; Intel® Xeon® Platinum 8470, 105MB cache, 52 cores, 104 threads, 2.0GHz to 3.8GHz Turbo, 350W; Intel® Xeon® Platinum 8480+, 105MB cache, 56 cores, 112 threads, 2.0GHz to 3.8GHz Turbo, 350W
• Chipset: Intel C741
• Graphics: Up to 2x Double wide graphics cards in PCIe Gen 5 slots – requires dual CPU system with 1400/2400W PSU; NVIDIA:; Nvidia RTX Pro 6000 Blackwell (300W), 96GB GDDR7; NVIDIA® RTX™ A800 40GB GDDR6 – no display output – requires T1000 for display; NVIDIA® RTX™ 6000 Ada, 48 GB GDDR6; Nvidia RTX Pro 5000 Blackwell (300W), 72GB GDDR7 (Coming soon); Nvidia RTX Pro 2000 Blackwell, 16GB GDDR7; Nvidia RTX Pro 4000 Blackwell, 24GB GDDR7; Nvidia RTX Pro 4500 Blackwell, 32GB GDDR7; Nvidia RTX Pro 5000 Blackwell, 48GB GDDR7; NVIDIA® RTX™ 5000 Ada, 32 GB GDDR; NVIDIA® RTX™ 4500 Ada, 24 GB GDDR6; NVIDIA® RTX™ 4000 Ada, 20 GB GDDR6; NVIDIA® A1000, 8 GB GDDR6; NVIDIA® A400, 4 GB GDDR6; NVIDIA® RTX™ A800 40GB GDDR6 – no display output – requires A1000 for display; AMD:; AMD Radeon™ W6400 LP/FH, 4GB GDDR6
• Memory: 16GB, 1 x 16GB, DDR5, 5600MT/s ECC; 32GB, 1 x 32GB, DDR5, 5600MT/s ECC; 32GB, 2 x 16GB, DDR5, 5600MT/s ECC; 64GB, 1 x 64GB, DDR5, 5600MT/s ECC; 64GB, 2 x 32GB, DDR5, 5600MT/s ECC; 64GB, 4 x 16GB, DDR5, 5600MT/s ECC; 96GB, 6 x 16GB, DDR5, 5600MT/s ECC; 128GB, 1 x 128GB, DDR5, 5600MT/s ECC; 128GB, 2 x 64GB, DDR5, 5600MT/s ECC; 128GB, 4 x 32GB, DDR5, 5600MT/s ECC; 128GB, 8 x 16GB, DDR5, 5600MT/s ECC; 192GB, 6 x 32GB, DDR5, 5600MT/s ECC; 192GB, 12 x 16GB, DDR5, 5600MT/s ECC; 256GB, 1 x 256GB, DDR5, 5600MT/s, ECC; 256GB, 2 x 128GB, DDR5, 5600MT/s, ECC; 256GB, 4 x 64GB, DDR5, 5600MT/s ECC; 256GB, 8 x 32GB, DDR5, 5600MT/s ECC; 256GB, 16 x 16GB, DDR5, 5600MT/s ECC; 384GB, 6 x 64GB, DDR5, 5600MT/s ECC; 384GB, 12 x 32GB, DDR5, 5600MT/s ECC; 384GB, 24 x 16GB, DDR5, 5600MT/s ECC; 512GB, 2 x 256GB, DDR5, 5600MT/s, ECC; 512GB, 4 x 128GB, DDR5, 5600MT/s, ECC; 512GB, 8 x 64GB, DDR5, 5600MT/s ECC; 512GB, 16 x 32GB, DDR5, 5600MT/s ECC; 512GB, 32 x 16GB, DDR5, 5600MT/s ECC; 768GB, 6 x 128GB, DDR5, 5600MT/s ECC; 768GB, 12 x 64GB, DDR5, 5600MT/s ECC; 768GB, 24 x 32GB, DDR5, 5600MT/s ECC; 1 TB 4x 256GB, DDR5, 5600MT/s, ECC; 1 TB, 8 x 128GB, DDR5, 5600MT/s, ECC; 1 TB, 16 x 64GB, DDR5, 5600MT/s ECC; 1 TB, 32 x 32GB, DDR5, 5600MT/s ECC; 1.5 TB, 6 x 256GB, DDR5, 5600MT/s, ECC; 1.5 TB, 12 x 128GB, DDR5, 5600MT/s ECC; 1.5 TB, 24 x 64GB, DDR5, 5600MT/s ECC; 2 TB 8 x 256GB, DDR5, 5600MT/s ECC; 2 TB 16 x 128GB, DDR5, 5600MT/s ECC; 2 TB, 32 x 64GB, DDR5, 5600MT/s ECC; 3 TB, 12 x 256GB, DDR5, 5600MT/s, ECC; 3 TB, 24 x 128GB, DDR5, 5600MT/s ECC; 4 TB, 16 x 256GB, DDR5, 5600MT/s ECC; 4 TB, 32 x 128GB, DDR5, 5600MT/s ECC; 6 TB, 24 x 256GB, DDR5, 5600MT/s ECC; 8 TB, 32 x 256GB, DDR5, 5600MT/s ECC; Note: Memory may clock down to 4800/4400MHz or lower (CPU dependent) and in configurations with 2 DIMMs.
• Storage: Boot drives: Boot from Dell Ultra Speed Drive Quad or Duo PCIe card; M.2 2280, 512GB, PCIe NVMe Gen4 x4, SSD, Class 40; M.2 2280, 1TB, PCIe NVMe Gen4 x4, SSD, Class 40; M.2 2280, 2TB, PCIe NVMe Gen4 x4, SSD, Class 40; M.2 2280, 4TB, PCIe NVMe Gen4 x4, SSD, Class 40; Data drives: 2.5-inch, 600GB, 15,000RPM, SAS, Enterprise HDD; 2.5-inch, 1.2TB, 10,000RPM, SAS, Enterprise HDD; 2.5-inch, 2.4TB, 10,000RPM, SAS, Enterprise HDD; 3.5-inch, 2TB, 7200RPM, SATA, Enterprise HDD; 3.5-inch, 4TB, 7200RPM, SATA, Enterprise HDD; 3.5-inch, 8TB, 7200RPM, SATA, Enterprise HDD; 3.5-inch, 12TB, 7200RPM, SATA, Enterprise HDD; 2.5-inch, 1.92TB, MU, SATA, Enterprise SSD; Storage controllers: Integrated 2x Intel chipset 6Gb/s SATA controllers with 4 ports each (total 8) for SATA HDD/SSD, 1 port for optical drive; Intel vROC SW SATA RAID 0,1,5,10; Optional Intel vROC Standard/Premium SW NVMe RAID; Optional PERC H755P SATA/SAS Motherboard Hardware RAID with 8GB cache
• Drive Bays: Support for up to (8) 2.5″ or 3.5″ SATA/SAS drives
• M.2 Slots: up to 8 x M.2 NVMe PCIe SSDs (Up to 8x 4TB drives on 2x Dell Precision Ultra-Speed Drive Quad x16 PCIe cards). Requires dual CPU config and graphics card in low profile riser slot
• Expansion Slots: 7 Slots in riser cards with Dual CPUs; Single CPU has 1x Gen 4 x16 (FH/FL) slot, 1x Gen 5 x16 (FH/FL) slot, 1x Gen 4 x16 low profile (FL) slot (Reserved primarily for NVMe boot with Dell Ultra-Speed Duo x8 LP PCIe card); Dual CPU has above slots plus 1x Gen 5 x16 double width slot, 2x Gen 4 x8 FH/HL slots, 1 Gen 4 x16 low profile (FL) slot; Up to 2x dual or single width graphics cards with dual CPUs
• Ports: Front Ports:; iDRAC Direct port (1x Micro USB 2.0); USB 2.0 port; VGA Port intended for IDRAC use; Rear Ports:; USB 2.0 port; USB 3.0 Gen1 port; iDRAC Enterprise Dedicated Network connector; VGA port intended for IDRAC use; (2) RJ45 Ethernet ports 1GbE LOM standard and one of three OCP3 NIC cards options in dedicated slot); (4) RJ45 Ethernet ports 1GbE (OCP3 card option); (4) RJ45 Ethernet ports 10GbE (OCP3 card option); (4) 10/25GbE SFP28 ports (OCP3 card option)
• Networking: Entry: Broadcom 5720 Dual Port 2x 1GbE LOM default or OCP3 NIC options; OCP 3.0 NIC Options: Intel i350 Quad Port 1GbE BASE-T, OCP NIC 3.0; Intel X710-T4L Quad Port 10GbE BASE-T, OCP NIC 3.0; Intel E810-XXVDA4 Quad Port 10/25GbE SFP28 Adapter, OCP NIC 3.0; Dedicated Broadcom® BCM54210 Ethernet LAN 10/100/1000 for iDRAC9 controller use with System Management tool suite
• Power Supply: One or two redundant, hot pluggable 800W (Platinum), 1100W (Titanium) and 1400W (120V) / 2400W (240V) (Platinum) power supplies.; Note: Dual non-redundant PSUs are often needed to provide sufficient power for richer CPU/GPU configurations at a given PSU power level. The 1400W/2400W PSUs have C19 power cords which require 20A @120V or 240V AC circuits.
• Operating System: Windows 11 for Workstations; Ubuntu® 24.04, 64-bit; Red Hat® Enterprise Linux® 9.3
• Security: Trusted Platform Module (TPM 2.0); Setup/BIOS Password, I/O Interface Security, lockable top cover and lockable front bezel, Dell Encryption Enterprise; Security software: McAfee® Small Business Security, Dell Encryption Personal, Dell Encryption Enterprise; TPM 2.0, lockable chassis with intrusion detection, self encrypting drives; Secure remote access with Teradici PCoIP dual and quad display remote workstation cards and Amulet Hotkey dual and quad display Zero Clients
• System Management: iDRAC9 Enterprise Dedicated Network Connector; Dedicated Broadcom® BCM54210 Ethernet LAN 10/100/1000 for iDRAC9 controller use with System Management tool suite
• Dimensions (H x W x D): U.S.: Height: 3.39in; Width (front): 18.98in.; Width (rear): 17.08in.; Depth with bezel: 30.40in.; Rest of the world: Height: 86.8mm; Width (front): 482mm; Width (rear): 434mm; Depth with bezel: 772.13mm
• Weight: Weight: Maximum: 65.36lbs.; Minimum: 46.25lbs. (ROW: Maximum: 29.64kg; Minimum: 20.98kg)
• Certifications: Product Safety, EMC and Environmental Datasheets; Dell Regulatory Compliance Home Page; Dell and the Environment
• Warranty: 3-year Basic warranty with hardware service with on-site/in-home service after remote diagnosis; 4-year Basic warranty with hardware service with on-site/in-home service after remote diagnosis; 5-year Basic warranty with hardware service with on-site/in-home service after remote diagnosis; 3-year/4-year/5-year ProSupport with Next Business Day on-site service; 3-year/4-year/5-year ProSupport Plus for Client with Next Business Day on-site service; 3-year/4-year/5-year Accidental Damage Service

Key Highlights

• 2U rack workstation with dual Intel Xeon Scalable processors, up to 128 cores
• Up to 2 double-width graphics cards in PCIe Gen5 slots and 8 TB of DDR5 memory
• 8 x M.2 NVMe boot/data drives, hot-swap redundant 1400W or 2400W power supplies and iDRAC management

Applications

• Rack-mounted VDI and shared engineering compute
• Multi-GPU AI and HPC workloads
• Data-centre-hosted CAD and simulation
• Media rendering farms

Configuration, availability and lead time depend on the required processor, memory, graphics, storage and delivery destination. Send your requirement to receive a quotation.
