| Form Factor | 4U AI server |
|---|---|
| Processor | 4th or 5th Gen Intel® Xeon® Scalable processors with 350 W TDP per processor |
| Chipset | Emmitsburg PCH |
| Memory | 32 x DDR5 DIMMs, with up to 5600 MT/s speed |
| Local Storage | Hot-swappable drives in the following configurations: |
| RAID | RAID 0, 1, 10, 1E, 5, 50, 6, or 60; supercapacitors for cache data protection from power failures; RAID level migration, drive roaming, self-diagnosis, and remote web-based configuration |
| GPU Card | 4 x dual-width or 10 x single-width GPU cards |
| Network | Multiple network expansion capabilities 2 x OCP 3.0 NICs, which can be configured as required and supports orderly hot swap and PCIe 5.0 |
| PCIe Expansion | Up to 10 x standard PCIe slots; supporting PCIe 5.0 |
| Fan Module | 8 x hot-swappable counter-rotating fan modules in N+1 redundancy |
| PSU | 4 x 1500 W Platinum, or 2000 W Platinum/Titanium hot-swappable PSUs with PSU1 and PSU2 in 1+1 redundancy and PSU3 and PSU4 in 1+1 redundancy |
| Management | The iBMC chip integrates one dedicated management GE network port, providing comprehensive management features such as fault diagnosis, automatic O&M, and hardware security hardening • The iBMC supports standard interfaces such as Redfish, SNMP, and IPMI 2.0; provides a remote management user interface based on HTML5/VNC KVM; supports out-of-band management functions such as monitoring, diagnosis, configuration, Agentless, and remote control for simplified management • Can be configured with the FusionDirector management software to provide advanced management features such as five intelligent technologies, enabling intelligent, automatic, visualized, and refined management through the lifecycle |
| OS | FusionOS, Microsoft Windows Server, SUSE Linux Enterprise Server, VMware ESXi, Red Hat Enterprise Linux, CentOS, Oracle, Ubuntu, Debian, and openEuler . |
| Security | Power-on password, administrator password, Trusted Platform Module (TPM) 2.0, security bezel, secure boot, and chassis intrusion detection |
| Operating Temperature | 5°C to 35°C (41°F to 95°F) (compliant with ASHRAE Class A1/A2) |
| Certification | CE, NRTL, CCC, FCC, VCCI, and RoHS |
| Installation Suite | L-shaped guide rails, adjustable guide rails, and holding rails |
| Dimensions (H x W x D) | 175 mm x 447 mm x 798 mm (6.89 in. x 17.60 in. x 31.42 in.) |
FusionServer G5200 V7
FusionServer G5200 V7 (G5200 V7) is a new-generation 4U 2-socket AI server that meets AI requirements of large-capacity storage.
Featuring robust performance, high reliability and security, efficient energy saving, simplified management and easy deployment, it can be used for training and inference workloads and is suitable for voice, image,and video analysis scenarios.
Overview
The FusionServer G5200 V7 is an enterprise server in a 4U chassis, configured for virtualisation, databases and general enterprise workloads. Its processor, memory, storage, networking and expansion options are summarised below.
At a glance
- Form Factor: 4U AI server
- Processor: 4th or 5th Gen Intel® Xeon® Scalable processors with 350 W TDP per processor
- Chipset: Emmitsburg PCH
- Memory: 32 x DDR5 DIMMs, with up to 5600 MT/s speed
- Local Storage: Hot-swappable drives in the following configurations:; Up to 28 x 3.5ʺ SAS/SATA drives; Up to 4 x NVMe SSDs Flash storage:; 2 x M.2 SSDs
- RAID: RAID 0, 1, 10, 1E, 5, 50, 6, or 60; supercapacitors for cache data protection from power failures; RAID level migration, drive roaming, self-diagnosis, and remote web-based configuration
- GPU Card: 4 x dual-width or 10 x single-width GPU cards
- Network: Multiple network expansion capabilities 2 x OCP 3.0 NICs, which can be configured as required and supports orderly hot swap and PCIe 5.0
- PCIe Expansion: Up to 10 x standard PCIe slots; supporting PCIe 5.0
- Fan Module: 8 x hot-swappable counter-rotating fan modules in N+1 redundancy
- PSU: 4 x 1500 W Platinum, or 2000 W Platinum/Titanium hot-swappable PSUs with PSU1 and PSU2 in 1+1 redundancy and PSU3 and PSU4 in 1+1 redundancy
- Management: The iBMC chip integrates one dedicated management GE network port, providing comprehensive management features such as fault diagnosis, automatic O&M, and hardware security hardening; The iBMC supports standard interfaces such as Redfish, SNMP, and IPMI 2.0; provides a remote management user interface based on HTML5/VNC KVM; supports out-of-band management functions such as monitoring, diagnosis, configuration, Agentless, and remote control for simplified management; Can be configured with the FusionDirector management software to provide advanced management features such as five intelligent…
- OS: FusionOS, Microsoft Windows Server, SUSE Linux Enterprise Server, VMware ESXi, Red Hat Enterprise Linux, CentOS, Oracle, Ubuntu, Debian, and openEuler .
- Security: Power-on password, administrator password, Trusted Platform Module (TPM) 2.0, security bezel, secure boot, and chassis intrusion detection
- Operating Temperature: 5°C to 35°C (41°F to 95°F) (compliant with ASHRAE Class A1/A2)
- Certification: CE, NRTL, CCC, FCC, VCCI, and RoHS
- Installation Suite: L-shaped guide rails, adjustable guide rails, and holding rails
- Dimensions (H x W x D): 175 mm x 447 mm x 798 mm (6.89 in. x 17.60 in. x 31.42 in.)
When to choose this server
Choose this platform where the deployment needs virtualisation, databases and general enterprise workloads. It uses a 4U chassis and 4 x 1500 W Platinum, or 2000 W Platinum/Titanium hot-swappable PSUs with PSU1… power; local storage options include Hot-swappable drives in the following configurations:; Up to 28 x 3.5ʺ SAS/SATA drives;….
Platform & compatibility
Supports processors: 4th or 5th Gen Intel® Xeon® Scalable processors with 350 W TDP per processor, memory: 32 x DDR5 DIMMs, with up to 5600 MT/s speed, network: Multiple network expansion capabilities 2 x OCP 3.0 NICs, which can be configured as required and supports orderly hot swap and PCIe 5.0, RAID: RAID 0, 1, 10, 1E, 5, 50, 6, or 60; supercapacitors for cache data protection…, OS: FusionOS, Microsoft Windows Server, SUSE Linux Enterprise Server, VMware ESXi, Red Hat Enterprise Linux, CentOS,…. Confirm the CPU, memory, drive and PSU configuration, plus rack rails, against your workload and rack before ordering.
Deployment notes
The FusionServer G5200 V7 is supplied as a configured platform; CPU, memory, storage and PSU are chosen at order time. out-of-band management: The iBMC chip integrates one dedicated management GE network port, providing comprehensive management features such as fault diagnosis, automatic…. power: 4 x 1500 W Platinum, or 2000 W Platinum/Titanium hot-swappable PSUs with PSU1 and PSU2 in…. network: Multiple network expansion capabilities 2 x OCP 3.0 NICs, which can be configured as required and supports…. Rack rails, power distribution and cooling follow the 4U chassis class and are confirmed at order time. Send the required CPU, memory and drive mix for a firm configuration and quote.
FAQ
What processors does it support? 4th or 5th Gen Intel® Xeon® Scalable processors with 350 W TDP per processor.
What memory does it take? 32 x DDR5 DIMMs, with up to 5600 MT/s speed.
What drives does it accept? Hot-swappable drives in the following configurations:; Up to 28 x 3.5ʺ SAS/SATA drives; Up to 4 x NVMe SSDs Flash storage:; 2 x M.2 SSDs.
How is it managed? The iBMC chip integrates one dedicated management GE network port, providing comprehensive management features such as fault diagnosis, automatic O&M, and hardware security hardening; The iBMC….
How do I get pricing? Send the required configuration; quotes depend on quantity, options and delivery destination.
