| Form Factor | 6U AI server |
|---|---|
| Processor | 2 x 5th Gen AMD EPYC™ 9005 Series processors, each with up to 500 W TDP |
| Memory | 24 x memory slots available for DDR5 DIMMs at up to 6400 MT/s |
| Local Storage | – Up to 10 x 2.5″ SAS/SATA/NVMe drives |
| RAID | RAID 0, 1, 10, 5, 50, 6, and 60; supercapacitors for cache data protection from power failures; |
| GPU | 10 x dual-width GPUs |
| Network | 1 x OCP 3.0 NIC |
| PCle Expansion | – Passthrough model：Up to 11 x standard PCIe 5.0 slots |
| Fan | GPU: 12 or 18 x 6056++ fans in N+1 redundancy |
| PSU | 8 x 3200 W single-input or dual-input CRPSs in N+N redundancy |
| Management | – The iBMC chip integrates one dedicated management GE port, providing comprehensive management features such as fault diagnosis, automatic O&M, and hardware security hardening. |
| OS | Microsoft Windows Server, SUSE Linux Enterprise Server, VMware ESXi, Red Hat Enterprise Linux, |
| Security | Power-on password, administrator password, Trusted Platform Module (TPM) 2.0, security bezel, |
| Operating Temperature | 5ºC to 35ºC (41ºF to 95ºF), compliant with ASHRAE Class A1/A2 |
| Certification | CE, UL, CCC, FCC, VCCI, and RoHS |
| Installation Suite | L-shaped guide rails, adjustable guide rails, and holding rails |
| Dimensions (H x W x D) | 263.9 mm x 447 mm x 850 mm (10.39 in. x 17.60 in. x 33.46 in.) |
FusionServer G6550 V8 Server
Overview
The FusionServer G6550 V8 Server is an enterprise server in a 6U chassis, configured for AI and GPU-accelerated workloads. Its processor, memory, storage, networking and expansion options are summarised below.
At a glance
- Form Factor: 6U AI server
- Processor: 2 x 5th Gen AMD EPYC™ 9005 Series processors, each with up to 500 W TDP
- Memory: 24 x memory slots available for DDR5 DIMMs at up to 6400 MT/s
- Local Storage: – Up to 10 x 2.5″ SAS/SATA/NVMe drives – supports two M.2 SSDs
- RAID: RAID 0, 1, 10, 5, 50, 6, and 60; supercapacitors for cache data protection from power failures; RAID level migration, drive roaming, self-diagnosis, and remote web-based configuration
- GPU: 10 x dual-width GPUs
- Network: 1 x OCP 3.0 NIC
- PCle Expansion: – Passthrough model：Up to 11 x standard PCIe 5.0 slots – Switch model：Up to 15 x standard PCIe 5.0 slots
- Fan: GPU: 12 or 18 x 6056++ fans in N+1 redundancy CPU: 6 x 6056++ fans in N+1 redundancy
- PSU: 8 x 3200 W single-input or dual-input CRPSs in N+N redundancy
- Management: – The iBMC chip integrates one dedicated management GE port, providing comprehensive management features such as fault diagnosis, automatic O&M, and hardware security hardening. – The iBMC supports standard interfaces such as Redfish, SNMP, and IPMI 2.0, provides a remote management user interface based on HTML5/VNC KVM, and supports out-of-band management functions such as monitoring, diagnosis, configuration, Agentless, and remote control for simplified management. – It is optional to configure FusionDirector that enables intelligent, automatic, visualized, and refined management throughout…
- OS: Microsoft Windows Server, SUSE Linux Enterprise Server, VMware ESXi, Red Hat Enterprise Linux, Oracle, Ubuntu, and openEuler
- Security: Power-on password, administrator password, Trusted Platform Module (TPM) 2.0, security bezel, secure boot, and chassis intrusion detection
- Operating Temperature: 5ºC to 35ºC (41ºF to 95ºF), compliant with ASHRAE Class A1/A2
- Certification: CE, UL, CCC, FCC, VCCI, and RoHS
- Installation Suite: L-shaped guide rails, adjustable guide rails, and holding rails
- Dimensions (H x W x D): 263.9 mm x 447 mm x 850 mm (10.39 in. x 17.60 in. x 33.46 in.)
When to choose this server
Choose this platform where the deployment needs AI and GPU-accelerated workloads. It uses a 6U chassis and 8 x 3200 W single-input or dual-input CRPSs in N+N redundancy power with GPU capability; local storage options include – Up to 10 x 2.5″ SAS/SATA/NVMe drives – supports two M.2 SSDs.
Platform & compatibility
Supports processors: 2 x 5th Gen AMD EPYC™ 9005 Series processors, each with up to 500 W TDP, memory: 24 x memory slots available for DDR5 DIMMs at up to 6400 MT/s, network: 1 x OCP 3.0 NIC, RAID: RAID 0, 1, 10, 5, 50, 6, and 60; supercapacitors for cache data protection from…, OS: Microsoft Windows Server, SUSE Linux Enterprise Server, VMware ESXi, Red Hat Enterprise Linux, Oracle, Ubuntu, and…. Confirm the CPU, memory, drive and PSU configuration, plus rack rails, against your workload and rack before ordering.
Deployment notes
The FusionServer G6550 V8 Server is supplied as a configured platform; CPU, memory, storage and PSU are chosen at order time. out-of-band management: – The iBMC chip integrates one dedicated management GE port, providing comprehensive management features such as fault diagnosis, automatic O&M, and…. power: 8 x 3200 W single-input or dual-input CRPSs in N+N redundancy. network: 1 x OCP 3.0 NIC. Rack rails, power distribution and cooling follow the 6U chassis class and are confirmed at order time. Send the required CPU, memory and drive mix for a firm configuration and quote.
FAQ
What processors does it support? 2 x 5th Gen AMD EPYC™ 9005 Series processors, each with up to 500 W TDP.
What memory does it take? 24 x memory slots available for DDR5 DIMMs at up to 6400 MT/s.
What drives does it accept? – Up to 10 x 2.5″ SAS/SATA/NVMe drives – supports two M.2 SSDs.
How is it managed? – The iBMC chip integrates one dedicated management GE port, providing comprehensive management features such as fault diagnosis, automatic O&M, and hardware security hardening. – The iBMC supports….
How do I get pricing? Send the required configuration; quotes depend on quantity, options and delivery destination.
